Intel HD Graphics 2000

英特尔HD图形2000(或英特尔图形媒体加速器HD 2000或GMA HD 2000)是一个集成显卡在Sandy Bridge处理器代号。它是包含在较慢的移动处理器(奔腾品牌如但称为只有英特尔HD图形)和在大多数桌面处理器。HD图形2000没有专用的内存但股价快速三级缓存与CPU核心和主要的记忆的一部分。由于涡轮推进,GPU的超频可以根据当前的CPU负载和功率消耗。GMA的HD 2000只提供一半的12个执行单元(EUs)英特尔GMA的HD 3000。 因为扳回数量的着色器,游戏性能只是compareable旧英特尔GMA高清(在Arrandale cpu)。我们的测试与桌面i5 - 2400显示性能水平的Geforce 105 m如这是G稍快。因此,只有低要求游戏像模拟人生3或魔兽世界玩家可在低细节设置流利。Altought 2 x反锯齿(AA)的支持,尽快的芯片是在呈现4 x AA。在Unigine谷基准类似的HD 3000 i7 - 2637 m例如达到相同的分数2 x AA和AA的4倍。 除了GPU,芯片还房子一些专用单位高清视频解码和编码。在以色列国防军英特尔展示了编码的时间长达3分钟1080 p的视频,iPhone在640年兼容的格式在只有14年代x360。另一个新奇的桑迪大桥GPU是嵌入式显示端口eDP连接内部显示。由于集成在32 nm建CPU和扳回数量的着色器,功耗很低,GPU应该也适合小型和轻型笔记本电脑。

HD Graphics Series

HD Graphics P530 24 @ 0.35 - 1.05 GHz64/128 Bit
HD Graphics 5600 24 @ 0.3 - 1.05 GHz64/128 Bit
HD Graphics 6000 48 @ 0.3 - 1 GHz64/128 Bit
HD Graphics 4600 20 @ 0.2 - 1.35 GHz64/128 Bit
HD Graphics 5500 24 @ 0.3 - 0.95 GHz64/128 Bit
HD Graphics 5000 40 @ 0.2 - 1.1 GHz64/128 Bit
HD Graphics 4400 20 @ 0.2 - 1.1 GHz64/128 Bit
HD Graphics 5300 24 @ 0.1 - 0.9 GHz64/128 Bit
HD Graphics 4000 16 @ 0.35 - 1.35 GHz64/128 Bit
HD Graphics (Broadwell) 12 @ 0.1 - 0.85 GHz64/128 Bit
HD Graphics 4200 20 @ 0.2 - 0.85 GHz64/128 Bit
HD Graphics (Skylake) 12 @ 0.3 - 0.8 GHz64/128 Bit
HD Graphics 405 (Braswell) 16 @ 0.32 - 0.7 GHz64/128 Bit
HD Graphics (Braswell) 16 @ 0.32 - 0.7 GHz64/128 Bit
HD Graphics 400 (Braswell) 12 @ 0.32 - 0.64 GHz64/128 Bit
HD Graphics (Haswell) 10 @ 0.2 - 1 GHz64/128 Bit
HD Graphics (Cherry Trail) 16 @ 0.2 - 0.6 GHz64/128 Bit
HD Graphics 3000 12 @ 0.35 - 1.35 GHz64/128 Bit
HD Graphics 2500 6 @ 0.65 - 1.15 GHz64/128 Bit
HD Graphics (Ivy Bridge) 6 @ 0.35 - 1.1 GHz64/128 Bit
HD Graphics 2000 6 @ 0.85 - 1.35 GHz64/128 Bit
HD Graphics (Sandy Bridge) 6 @ 0.35 - 1.1 GHz64/128 Bit
HD Graphics (Bay Trail) 4 @ 0.31 - 0.9 GHz32/64/128 Bit
CodenameSandy Bridge
ArchitectureGen. 6 Sandy Bridge
Pipelines6 - unified
Core Speed850/1100 - 1350 (Boost) MHz
Memory Bus Width64/128 Bit
Shared Memoryyes
APIDirectX 10.1, Shader 4.1
technology32 nm
Date of Announcement01.02.2011
CPU in HD Graphics 2000GPU Base SpeedGPU Boost / Turbo
Intel Core i5-24004 x 3100 MHz, 95 W850 MHz1100 MHz

Benchmarks

3DMark Vantage
3DM Vant. Perf. total +
3DMark Vantage - 3DM Vant. Perf. total
min: 789     avg: 896     median: 895.5 (0%)     max: 1002 Points
+ 2 benchmarks and specifications   + Show comparison chart
3DM Vant. Perf. GPU no PhysX +
3DMark Vantage - 3DM Vant. Perf. GPU no PhysX
min: 626     avg: 695     median: 694.5 (0%)     max: 763 Points
+ 2 benchmarks and specifications   - Hide comparison chart
ATI Radeon HD 3200
62 -91%
...
Intel HD Graphics (Bay Trail)
512 -26%
ATI Mobility Radeon HD 4330
515 -26%
ATI Mobility Radeon HD 4530
560 -19%
AMD Radeon HD 7310
564 -19%
AMD Radeon HD 6310
584 -16%
NVIDIA ION 2
622 -11%
ATI Mobility Radeon HD 3650
635 -9%
NVIDIA GeForce G 105M
646 -7%
NVIDIA GeForce 9500M GS
690 -1%
Intel HD Graphics 2000
695
Intel HD Graphics (Sandy Bridge)
736 6%
AMD Radeon HD 6320
739 6%
ATI Mobility Radeon HD 5430
750 8%
NVIDIA NVS 2100M
769 11%
ATI Mobility Radeon HD 540v
782 13%
ATI Mobility FireGL V5700
803 16%
ATI Mobility Radeon HD 4550
806 16%
NVIDIA GeForce 8600M GT
843 21%
ATI Mobility Radeon HD 4570
853 23%
...
NVIDIA GeForce RTX 4090 Laptop GPU
132443 18957%
max:
AMD Radeon RX 7900 XTX
170928 24494%
0%
100%
3DMark 2001SE - 3DMark 2001 - Standard
15201 Points (16%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark 03 - 3DMark 03 - Standard
min: 6077     avg: 7083     median: 7083 (4%)     max: 8089 Points
+ 2 benchmarks and specifications   + Show comparison chart
3DMark 05 - 3DMark 05 - Standard
min: 4585     avg: 5194     median: 5193.5 (6%)     max: 5802 Points
+ 2 benchmarks and specifications   - Hide comparison chart
Intel Graphics Media Accelerator (GMA) 500
133.4 -97%
...
AMD Radeon HD 7340
4451 -14%
AMD Radeon HD 7400G
4515 -13%
ATI Mobility Radeon HD 3470 Hybrid X2
4527 -13%
Intel HD Graphics (Sandy Bridge)
4691 -10%
NVIDIA GeForce Go 7600 GT
4909 -5%
NVIDIA GeForce Go 6800 Ultra
5000 -4%
Intel HD Graphics (Ivy Bridge)
5085 -2%
ATI Mobility Radeon HD 4330
5113 -2%
AMD Radeon HD 8240
5118 -1%
Intel HD Graphics 2000
5194
AMD Radeon HD 7600G
5470 5%
ATI Mobility Radeon HD 5430
5509 6%
AMD Radeon HD 8330
5598 8%
ATI Mobility Radeon X1800
5600 8%
NVIDIA GeForce 9500M G
5766 11%
Intel UHD Graphics 605
5802 12%
AMD Radeon HD 8450G
5908 14%
NVIDIA GeForce Go 7900 GS
5937 14%
ATI Mobility Radeon HD 4350
5953 15%
...
AMD Radeon RX 7600M XT
68064 1210%
max:
NVIDIA GeForce RTX 4080 Super
87172 1578%
0%
100%
3DMark 06 3DMark 06 - Standard 1280x1024 +
3DMark 06
min: 1217     avg: 2222     median: 2288 (3%)     max: 3162 Points
+ 3 benchmarks and specifications   + Show comparison chart
Unigine Heaven 2.1 - Heaven 2.1 high
5.3 fps (1%)
+ 1 benchmarks and specifications   - Hide comparison chart
AMD Radeon HD 7310
0.6 -89%
...
AMD Radeon HD 6310
1.2 -77%
AMD Radeon HD 6320
1.5 -72%
AMD Radeon HD 6250
2.5 -53%
Intel HD Graphics (Bay Trail)
2.767 -48%
AMD Radeon HD 8610G
4.3 -19%
Intel HD Graphics (Braswell)
4.9 -8%
AMD Radeon HD 7600G
5 -6%
AMD Radeon R2 (Mullins/Beema/Carrizo-L)
5.1 -4%
AMD Radeon HD 7640G
5.1 -4%
Intel HD Graphics 2000
5.3
AMD Radeon HD 7470M
5.4 2%
AMD Radeon HD 6520G
5.4 2%
AMD Radeon R3 (Mullins/Beema)
5.45 3%
AMD Radeon HD 6480G
5.5 4%
Intel HD Graphics (Cherry Trail)
5.7 8%
Intel HD Graphics (Sandy Bridge)
5.7 8%
AMD Radeon HD 6470M
6.2 17%
AMD Radeon HD 6490M
6.7 26%
AMD Radeon HD 7450M
6.85 29%
...
NVIDIA Quadro RTX 5000 (Laptop)
532 9938%
0%
100%
Windows 7 Experience Index - Win7 Gaming graphics
5.6 Points (71%)
+ 2 benchmarks and specifications   + Show comparison chart
Windows 7 Experience Index - Win7 Graphics
min: 4.5     avg: 4.9     median: 4.9 (61%)     max: 5.2 Points
+ 2 benchmarks and specifications   + Show comparison chart
Cinebench R10 Cinebench R10 Shading (32bit) +
Cinebench R10 - Cinebench R10 Shading (32bit)
min: 1169     avg: 2298     median: 2298 (2%)     max: 3427 points
+ 2 benchmarks and specifications   + Show comparison chart
Cinebench R11.5 Cinebench R11.5 OpenGL 64 Bit +
Cinebench R11.5 - Cinebench R11.5 OpenGL 64 Bit
min: 2.69     avg: 5.1     median: 5.9 (2%)     max: 6.68 fps
+ 3 benchmarks and specifications   + Show comparison chart
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance

Game Benchmarks

The following benchmarks stem from our benchmarks of review laptops. The performance depends on the used graphics memory, clock rate, processor, system settings, drivers, and operating systems. So the results don't have to be representative for all laptops with this GPU. For detailed information on the benchmark results, click on the fps number.

Diablo III

Diablo III

2012
low 1024x768
24.1  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Mass Effect 3

Mass Effect 3

2012
low 1280x720
11.9  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Anno 2070

Anno 2070

2011
low 1024x768
18.9 21.5 ~ 20 fps    + Compare
med. 1366x768
8  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
The Elder Scrolls V: Skyrim

The Elder Scrolls V: Skyrim

2011
low 1280x720
14  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Fifa 12

Fifa 12

2011
low 800x600
117  fps    + Compare
med. 1024x768
56  fps    + Compare
high 1360x768
37  fps    + Compare
ultra 1920x1080
21  fps    + Compare
» With all tested laptops playable in detail settings high.
F1 2011

F1 2011

2011
low 800x600
37  fps    + Compare
med. 1024x768
19  fps    + Compare
» With all tested laptops playable in detail settings low.
Deus Ex Human Revolution

Deus Ex Human Revolution

2011
low 1024x768
23.3 26 ~ 25 fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Dirt 3

Dirt 3

2011
low 800x600
53  fps    + Compare
med. 1024x768
21.4  fps    + Compare
high 1360x768
13.3  fps    + Compare
» With all tested laptops playable in detail settings low.
The Witcher 2: Assassins of Kings

The Witcher 2: Assassins of Kings

2011
low 1024x768
9  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Crysis 2

Crysis 2

2011
low 800x600
18  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Total War: Shogun 2

Total War: Shogun 2

2011
low 1024x768
43.2  fps    + Compare
» With all tested laptops playable in detail settings low.
Call of Duty: Black Ops

Call of Duty: Black Ops

2010
low 800x600
26  fps    + Compare
med. 1024x768
17  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Fifa 11

Fifa 11

2010
med. 1024x768
68 71 ~ 70 fps    + Compare
high 1360x768
34 40 ~ 37 fps    + Compare
ultra 1920x1080
19 22 ~ 21 fps    + Compare
» With most tested laptops playable in detail settings high.
Mafia 2

Mafia 2

2010
low 800x600
-1 16.9 ~ 8 fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
StarCraft 2

StarCraft 2

2010
low 1024x768
62  fps    + Compare
med. 1360x768
12  fps    + Compare
high 1360x768
9  fps    + Compare
ultra 1920x1080
5  fps    + Compare
» With all tested laptops playable in detail settings low.
Metro 2033

Metro 2033

2010
low 800x600
27  fps    + Compare
med. 1360x768
11  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Dawn of War II - Chaos Rising

Dawn of War II - Chaos Rising

2010
low 1024x768
26.4  fps    + Compare
med. 1366x768
10.4  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Battlefield: Bad Company 2

Battlefield: Bad Company 2

2010
low 1024x768
21.2 23 ~ 22 fps    + Compare
med. 1366x768
12 13.5 ~ 13 fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
CoD Modern Warfare 2

CoD Modern Warfare 2

2009
low 800x600
50  fps    + Compare
med. 1024x768
14  fps    + Compare
» With all tested laptops playable in detail settings low.
Risen

Risen

2009
low 800x600
26 48 ~ 37 fps    + Compare
med. 1024x768
11 15.5 ~ 13 fps    + Compare
high 1366x768
7.8  fps    + Compare
» With most tested laptops playable in detail settings low.
Resident Evil 5

Resident Evil 5

2009
low 800x600
62  fps    + Compare
high 1360x768
12.7  fps    + Compare
ultra 1920x1080
6.1  fps    + Compare
» With all tested laptops playable in detail settings low.
Need for Speed Shift

Need for Speed Shift

2009
low 800x600
30  fps    + Compare
med. 1024x768
12  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Colin McRae: DIRT 2

Colin McRae: DIRT 2

2009
low 800x600
27.1  fps    + Compare
med. 1024x768
17.9  fps    + Compare
ultra 1920x1080
12.7  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Anno 1404

Anno 1404

2009
low 1024x768
32  fps    + Compare
ultra 1280x1024
5  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Sims 3

Sims 3

2009
low 800x600
107  fps    + Compare
med. 1024x768
24  fps    + Compare
high 1280x1024
13  fps    + Compare
» With all tested laptops playable in detail settings low.
F.E.A.R. 2

F.E.A.R. 2

2009
low 800x600
73  fps    + Compare
med. 1024x768
20  fps    + Compare
» With all tested laptops playable in detail settings low.
GTA IV - Grand Theft Auto

GTA IV - Grand Theft Auto

2008
low 800x600
-1  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Left 4 Dead

Left 4 Dead

2008
high 1024x768
31  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Far Cry 2

Far Cry 2

2008
low 640x480
27.9 49 ~ 38 fps    + Compare
high 1024x768
13 13 ~ 13 fps    + Compare
ultra 1920x1080
5.2  fps    + Compare
» With most tested laptops playable in detail settings low.
Crysis Warhead

Crysis Warhead

2008
low 800x600
30  fps    + Compare
ultra 1024x768
4  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Trackmania Nations Forever

Trackmania Nations Forever

2008
low 640x480
166  fps    + Compare
high 1024x768
39.3  fps    + Compare
ultra 1920x1080
13.7  fps    + Compare
» With all tested laptops playable in detail settings high.
Call of Duty 4 - Modern Warfare

Call of Duty 4 - Modern Warfare

2007
low 800x600
74  fps    + Compare
med. 1024x768
27  fps    + Compare
high 1280x1024
11  fps    + Compare
» With all tested laptops playable in detail settings low.
Supreme Commander - FA Bench

Supreme Commander - FA Bench

2007
low 1024x768
27  fps    + Compare
med. 1024x768
16  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Crysis - GPU Benchmark

Crysis - GPU Benchmark

2007
low 1024x768
25 37 ~ 31 fps    + Compare
med. 1024x768
13.8 14.7 ~ 14 fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Crysis - CPU Benchmark

Crysis - CPU Benchmark

2007
low 1024x768
33.3  fps    + Compare
med. 1024x768
13.7  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
World in Conflict - Benchmark

World in Conflict - Benchmark

2007
low 800x600
78  fps    + Compare
med. 1024x768
21  fps    + Compare
high 1024x768
10  fps    + Compare
ultra 1920x1080
4  fps    + Compare
» With all tested laptops playable in detail settings low.
Half Life 2 - Lost Coast Benchmark

Half Life 2 - Lost Coast Benchmark

2005
high 1024x768
100.6  fps    + Compare
» With all tested laptops playable in detail settings high.
Quake 4

Quake 4

2005
ultra 1024x768
44  fps    + Compare
» With all tested laptops playable in detail settings ultra.
World of Warcraft

World of Warcraft

2005
low 800x600
144  fps    + Compare
med. 1024x768
36  fps    + Compare
high 1280x1024
9  fps    + Compare
» With all tested laptops playable in detail settings med..
Counter-Strike Source

Counter-Strike Source

2004
low 640x480
210  fps    + Compare
high 1024x768
70  fps    + Compare
» With all tested laptops playable in detail settings high.
Doom 3

Doom 3

2004
low 640x480
52  fps    + Compare
ultra 1024x768
44.1  fps    + Compare
» With all tested laptops playable in detail settings ultra.
Quake 3 Arena - Timedemo

Quake 3 Arena - Timedemo

1999
high 1024x768
243  fps    + Compare
» With all tested laptops playable in detail settings high.
lowmed.highultraQHD4K
Diablo III24.1
Mass Effect 311.9
Anno 2070208
The Elder Scrolls V: Skyrim14
Fifa 12117563721
F1 20113719
Deus Ex Human Revolution25
Dirt 35321.413.3
The Witcher 2: Assassins of Kings9
Crysis 218
Total War: Shogun 243.2
Call of Duty: Black Ops2617
Fifa 11703721
Mafia 28
StarCraft 2621295
Metro 20332711
Dawn of War II - Chaos Rising26.410.38
Battlefield: Bad Company 22213
CoD Modern Warfare 25014
Risen37137.8
Resident Evil 56212.76.1
Need for Speed Shift3012
Colin McRae: DIRT 227.117.912.7
Anno 1404325
Sims 31072413
F.E.A.R. 27320
GTA IV - Grand Theft Auto-1
Left 4 Dead31
Far Cry 238135.2
Crysis Warhead304
Trackmania Nations Forever16639.313.7
Call of Duty 4 - Modern Warfare742711
Supreme Commander - FA Bench2716
Crysis - GPU Benchmark3114
Crysis - CPU Benchmark33.313.7
World in Conflict - Benchmark7821104
Half Life 2 - Lost Coast Benchmark100.6
Quake 444
World of Warcraft144369
Counter-Strike Source21070
Doom 35244.1
Quake 3 Arena - Timedemo243
< 30 fps
< 60 fps
< 120 fps
≥ 120 fps		14
12
7
3		19
2
1
9
4
2
1		10
2







For more games that might be playable and a list of all games and graphics cards visit our Gaming List

v1.28
log 10. 12:42:10

#0 ran 0s before starting gpusingle class +0s ... 0s

#1 no ids found in url (should be separated by "_") +0s ... 0s

#2 not redirecting to Ajax server +0s ... 0s

#3 did not recreate cache, as it is less than 5 days old! Created at Sun, 10 Nov 2024 05:29:51 +0100 +0.001s ... 0.001s

#4 no comparison url found in template nbc.compare_page_1 needed +0.031s ... 0.032s

#5 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.032s

#6 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.032s

#7 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.032s

#8 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.033s

#9 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.033s

#10 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.033s

#11 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.033s

#12 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.033s

#13 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.033s

#14 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.033s

#15 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.033s

#16 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.034s

#17 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.034s

#18 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.034s

#19 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.034s

#20 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.034s

#21 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.034s

#22 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.034s

#23 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.035s

#24 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.035s

#25 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.035s

#26 composed specs +0s ... 0.035s

#27 did output specs +0s ... 0.035s

#28 start showIntegratedCPUs +0s ... 0.035s

#29 getting avg benchmarks for device 1958 +0.013s ... 0.048s

#30 got single benchmarks 1958 +0.032s ... 0.08s

#31 got avg benchmarks for devices +0s ... 0.08s

#32 min, max, avg, median took s +0.213s ... 0.293s

#33 before gaming benchmark output +0s ... 0.293s

#34 Got 101 rows for game benchmarks. +0.005s ... 0.298s

#35 composed SQL query for gamebenchmarks +0s ... 0.298s

#36 got data and put it in $dataArray +0.021s ... 0.32s

#37 benchmarks composed for output. +0.766s ... 1.086s

#38 no comparison url found in template nbc.compare_page_1 needed +0.003s ... 1.089s

#39 return log +0s ... 1.089s

Please share our article, every link counts!

» Comparison of GPUs
Detailed list of all laptop GPUs sorted by class and performance.

» Benchmark List
Sort and restrict laptop GPUs based on performance in synthetic benchmarks.

» Notebook Gaming List
Playable games for each graphics card and their average FPS results.

Class 1

NVIDIA GeForce RTX 4090 Laptop GPU
NVIDIA RTX 5000 Ada Generation Laptop GPU
Radeon RX 7900M
NVIDIA GeForce RTX 4080 Laptop GPU
NVIDIA RTX 4000 Ada Generation Laptop GPU
NVIDIA RTX 3500 Ada Generation Laptop GPU
GeForce RTX 3080 Ti Laptop GPU
NVIDIA GeForce RTX 4070 Laptop GPU
NVIDIA RTX 3000 Ada Generation Laptop GPU
RTX A5500 Laptop GPU
GeForce RTX 3080 Laptop GPU
M4 20-core GPU
Radeon RX 6850M XT
GeForce RTX 3070 Ti Laptop GPU
RTX A4500 Laptop GPU
RTX A5000 Laptop GPU
NVIDIA GeForce RTX 4060 Laptop GPU
NVIDIA RTX 2000 Ada Generation Laptop GPU
Quadro RTX 6000 (Laptop)
Radeon RX 6800M
GeForce RTX 2080 Super Mobile
GeForce RTX 3070 Laptop GPU
RTX A4000 Laptop GPU *

Class 2

Radeon RX 6800S
Radeon RX 7600M XT *
Radeon RX 7700S *
M3 Max 40-Core GPU *
M2 Max 38-Core GPU *
GeForce RTX 2080 Mobile
Radeon RX 6700M
M3 Max 30-Core GPU *
Quadro RTX 5000 (Laptop)
Radeon RX 7600M *
M2 Max 30-Core GPU *
GeForce RTX 3060 Laptop GPU
M1 Max 32-Core GPU *
Radeon RX 7600S
GeForce RTX 2070 Super Mobile
GeForce RTX 2080 Super Max-Q
RTX A3000 Laptop GPU
M1 Max 24-Core GPU *
A770M *
Radeon RX 6650M XT *
M3 Pro 18-Core GPU *
M2 Pro 19-Core GPU *
Radeon RX 6650M
Radeon RX 6600M
Radeon RX 6700S
GeForce RTX 2070 Mobile
Quadro RTX 5000 Max-Q
GeForce RTX 2080 Max-Q
Radeon RX 5700M *
GeForce GTX 1080 Mobile
Quadro RTX 4000 (Laptop)
M3 Pro 14-Core GPU *
M2 Pro 16-Core GPU *
M1 Pro 16-Core GPU *
Radeon PRO W6600M *
GeForce RTX 2070 Super Max-Q
Quadro RTX 4000 Max-Q *
M1 Pro 14-Core GPU *
GeForce RTX 2070 Max-Q *
Radeon RX 6600S *
Quadro P5200
Quadro RTX 3000 (Laptop) *
GeForce RTX 2060 Mobile
Quadro RTX 3000 Max-Q *
GeForce GTX 1080 Max-Q
GeForce GTX 1070 Mobile
GeForce RTX 2060 Max-Q *
Quadro P4200
NVIDIA GeForce RTX 4050 Laptop GPU
Nvidia RTX 1000 Ada Generation Laptop GPU
RTX A2000 Laptop GPU
A730M *
Radeon Pro 5600M *
Radeon RX 5600M
Quadro P5000
GeForce GTX 1660 Ti Mobile
GeForce RTX 3050 Ti Laptop GPU
GeForce RTX 3050 6GB Laptop GPU
A570M *
RTX A1000 Laptop GPU
GeForce GTX 1070 Max-Q
A550M *
Quadro P5000 Max-Q *
GeForce RTX 3050 A Laptop GPU
GeForce RTX 3050 4GB Laptop GPU
Nvidia RTX 500 Ada Generation Laptop GPU
A530M *
GeForce GTX 1660 Ti Max-Q
RTX A500 Laptop GPU
Radeon RX 6550M *
Radeon RX 6500M
Radeon RX 6550S *
GeForce GTX 980 (Laptop)
Quadro M5500
Quadro P4000
Quadro T2000 (Laptop) *
GeForce GTX 1060 Mobile
GeForce GTX 1650 Ti Mobile
A370M *
Radeon RX 5500M
Radeon Pro 5500M *
Quadro P4000 Max-Q
Quadro P3200
Radeon RX 580X (Laptop) *
Radeon RX 580 (Laptop)
Radeon RX 6450M *
GeForce RTX 2050 Mobile
Arc 140V *
GeForce MX570 *
Radeon RX 6300M *
Arc 130V *
GeForce GTX 1650 Mobile
Radeon Pro 5300M
Radeon RX 5300M
Quadro P3000
GeForce GTX 1060 Max-Q
Quadro P3000 Max-Q *
GeForce GTX 1650 Ti Max-Q *
Quadro T2000 Max-Q *
Radeon Pro WX 7100 *
Radeon RX 570X (Laptop) *
Radeon RX 570 (Laptop) *
Radeon RX 470 (Laptop) *
GeForce GTX 1650 Max-Q *
T1200 Laptop GPU *
Radeon 890M *
Quadro T1000 (Laptop) *
Quadro T1000 Max-Q *
A310 *
Arc 8-Core *
A350M *
Arc 7-Core *
T600 Laptop GPU *
T550 Laptop GPU *

Class 3

M4 8-Core GPU *
GeForce GTX 980M
Vega M GH
Quadro M5000M
Radeon Pro Vega 20
Radeon 880M *
Adreno 830 *
Adreno X1-85 4.6 TFLOPS *
Radeon 780M *
GeForce MX550
GeForce GTX 1050 Ti Mobile
Radeon 680M
Quadro P2000
Quadro P2000 Max-Q
Quadro M4000M
GeForce GTX 970M
T500 Laptop GPU *
GeForce MX450 *
Radeon R9 M395X
GeForce GTX 1050 Ti Max-Q *
Radeon Pro Vega 16
Vega M GL / 870
WX Vega M GL
Radeon R9 M485X
Quadro M3000M
GeForce GTX 1050 Mobile
FirePro W7170M
Radeon R9 M395
GeForce GTX 1050 Max-Q *
Radeon 760M *
Adreno X1-85 3.8 TFLOPS *
Radeon Radeon Steam Deck 8CU
Radeon 660M
Radeon Pro WX 4150 *
GeForce GTX 965M
Radeon RX 560X (Laptop)
Radeon RX 560 (Laptop)
Quadro M2200
Radeon RX 460 (Laptop)
Quadro P1000
Radeon R9 M390
Xe MAX
Radeon Pro 560X
Radeon Pro 560
Radeon Pro 460
Radeon Pro WX 4130 *
Iris Xe G7 96EUs
GeForce MX350
GeForce GTX 960M
Quadro M1200
Quadro P620 *
Radeon RX 550X (Laptop)
Radeon RX 550 (Laptop)
Radeon RX 640
Radeon Pro WX 3200 *
Radeon Pro 555X
Radeon Pro 555
Radeon Pro 455
Quadro P600
GeForce MX250
GeForce MX330
GeForce MX150
Iris Xe G7 80EUs
Graphics 4-Core *
Quadro M2000M
Radeon RX 540X *
Radeon Pro WX 2100 *
Radeon RX 540 *
Radeon Pro WX 3100 *
GeForce GTX 950M
Radeon Pro 450
Adreno X1-45 2.1 TFLOPS *
Radeon 630
Radeon 540X *
Radeon R9 M470X *
Radeon R9 M385X
Quadro P520
Quadro M1000M
Quadro M620 *
GeForce 945M
Quadro P500 *
UHD Graphics 64EUs
Iris Plus Graphics G7 (Ice Lake 64 EU) *
Vega 10 *
Iris Pro Graphics P580
Iris Pro Graphics 580
Adreno X1-45 1.7 TFLOPS *
Radeon R9 M470 *
FirePro W5170M *
Radeon R9 M370X
Vega 9
FirePro W5130M
UHD Graphics Xe G4 48EUs *
UHD Graphics 32EUs
UHD Graphics Xe 32EUs (Tiger Lake-H) *
UHD Graphics 750
Radeon 740M *
UHD Graphics 730
GeForce MX230
Vega 8 *
Vega 7
Radeon R7 M465
Iris Pro Graphics 6200
GeForce MX130
GeForce 940MX
Quadro M520
Vega 8
GeForce 940M
Iris Plus Graphics G4 (Ice Lake 48 EU)
GeForce 930MX
Quadro M600M
FirePro W4190M
Radeon R9 M375
Iris Plus Graphics 655
Radeon R7 M445
Quadro M500M
Iris Plus Graphics 650
GeForce 930M
Iris Graphics 550
Radeon 530
Radeon 625
Vega 6 *
Iris Plus Graphics 645
GeForce MX110 *
Iris Plus Graphics 640
GeForce 920MX
Iris Graphics 540
UHD Graphics 24EUs (Alder Lake-N) *
Radeon R7 (Bristol Ridge) *
Radeon R7 M460 *
Radeon R7 M360
GeForce 920M
Radeon R8 M445DX
Radeon 620
Radeon R7 M440
Radeon R7 M340
Radeon 520
Radeon 610
Radeon Graphics (Ryzen 7000)
Radeon 610M *
Vega 6 *
Vega 5 *
UHD Graphics G1 (Ice Lake 32 EU)
UHD Graphics Xe 16EUs (Tiger Lake-H) *
HD Graphics 530
Radeon R5 (Bristol Ridge)
UHD Graphics 620
HD Graphics 620
Adreno 690 *
Adreno 685 *
Adreno 680 *
Radeon R5 M330
Radeon R5 M430
Vega 3 *
GeForce 910M
HD Graphics 520
Iris Graphics 6100

Class 4

Radeon R5 M320 *
Radeon R5 M315 *
Radeon R5 M420 *
Vega 2 *
Radeon R5 (Stoney Ridge)
HD Graphics 6000
UHD Graphics (Jasper Lake 32 EU) *
UHD Graphics 617
UHD Graphics 615
UHD Graphics (Jasper Lake 24 EU) *
HD Graphics 615
HD Graphics 515
UHD Graphics 610
HD Graphics 610
HD Graphics 510
UHD Graphics (Jasper Lake 16 EU)
UHD Graphics 605
HD Graphics 505
Radeon R4 (Stoney Ridge)
Radeon R2 (Stoney Ridge)
VideoCore VII *
UHD Graphics 600
HD Graphics 500
HD Graphics 405 (Braswell)
HD Graphics (Braswell)
HD Graphics 400 (Braswell)

Class 5

HD Graphics 2000

* Approximate position of the graphics adapter
