Intel Pentium N3520

Intel N3520

Intel Pentium N3520是一款为入门级笔记本电脑设计的高能效四核整合系统芯片。它的基本频率为2.17GHz，并可以加速到2.42GHz（峰值频率）。这款Pentium处理器属于Bay Trail-M平台。得利于特别优化设计的22纳米低功耗制程（P1271）和三栅极晶体管技术，它的性能和能效明显高于前代Intel Atom处理器产品。 架构 它的处理器核心基于新的Silvermont架构，它第一次采用了乱序执行技术的设计。更高的流水线利用率和很多其他的改进（优化的分支预测，缓存的提升，加强的解码器）帮助单位频率性能提升了约50%。不过，相对于前代，它没有采用超线程技术。其他重要改进还有新增加的对SSE 4.1和4.2，AES-NI指令集的支持（根据型号）。 性能 得力于最高运行于2.4GHz的四个处理器核心，Pentium N3520明显快于前代的Intel Atom处理器如N2800。它的平均表现介于AMD Kabini APU A4-5100和A6-5200之间。。它的性能足够满足日常应用如上网和办公，但不适合大型软件和最新游戏。 图形 HD Graphics（Bay Trail）基于同样使用在Ivy Bridge系列处理器中（如HD Graphics 4000）的Intel Gen7架构，支持DirectX 11。由于只有4个执行单元（EU）和313-854MHz的较低运行频率，它的性能低于HD Graphics（Ivy Bridge）。因此，只有较老和要求较低的Windows游戏可以流畅运行。相比于较慢的Pentium N3510，N3520的显卡快约14%（750 vs. 854MHz）。 功耗 这块整合系统芯片的热设计功率为7.5W（SDP为4.5W）。因此，它可以用于紧凑设计的轻薄笔记本电脑和变形本中，不需要大型的散热系统。

SeriesIntel Pentium
CodenameBay Trail-M

Series: Pentium Bay Trail-M

Intel Pentium N35402.16 - 2.66 GHz4 / 4 cores
Intel Pentium N35302.16 - 2.58 GHz4 / 4 cores
Intel Pentium N3520 « 2.17 - 2.42 GHz4 / 4 cores
Intel Pentium N35102 GHz4 / 4 cores
Clock Rate2167 - 2420 MHz
Level 1 Cache224 KB
Level 2 Cache2 MB
Number of Cores / Threads4 / 4
Power Consumption (TDP = Thermal Design Power)7.5 Watt
Manufacturing Technology22 nm
Max. Temperature100 °C
SocketFCBGA1170
FeaturesIntel HD Graphics (Bay Trail, max. 854 MHz), Intel 64, SSE 4.1, SSE 4.2, Wireless Display
GPUIntel HD Graphics (Bay Trail) (313 - 854 MHz)
64 Bit64 Bit support
Architecturex86
Starting Price$161 U.S.
Announcement Date12/01/2013
Product Link (external)ark.intel.com

Benchmarks

Cinebench R15 - Cinebench R15 CPU Multi 64 Bit
min: 128     avg: 139.3     median: 144 (1%)     max: 146 Points
+ 3 benchmarks and specifications   - Hide comparison chart
AMD A4-1200
31 -78%
...
Intel Core i5-4300Y
133 -5%
AMD A8-7100
133 -5%
Intel Atom x7-Z8750
133 -5%
Intel Celeron 3867U
134 -4%
Intel Atom x5-Z8550
134 -4%
AMD A4-6210
134.5 -3%
Intel Celeron 4205U
136 -2%
Intel Pentium N3700
138.4 -1%
AMD A6-7310
139 0%
Intel Pentium N3520
139.3
Intel Pentium N3710
139.7 0%
AMD E2-7110
140 1%
Intel Celeron 3865U
142 2%
Intel Core i5-4210Y
145.8 5%
Intel Celeron N3450
146.8 5%
Intel Core M-5Y51
149.7 7%
Intel Core i3-3217U
152 9%
AMD A10-7300
152 9%
Intel Core i3-4020Y
152 9%
...
AMD Ryzen 9 7945HX3D
5600 3920%
max:
AMD Ryzen Threadripper PRO 7995WX
15842 11273%
0%
100%
Cinebench R15 - Cinebench R15 CPU Single 64 Bit
min: 38     avg: 38.3     median: 38 (11%)     max: 39 Points
+ 3 benchmarks and specifications   - Hide comparison chart
AMD A4-1200
19 -50%
...
Intel Atom x5-Z8500
35.75 -7%
Intel Atom x5-Z8550
36 -6%
AMD E2-7110
37 -3%
Intel Atom Z3795
37 -3%
Intel Pentium N3700
37.4 -2%
AMD A4-6210
37.5 -2%
Intel Atom x7-Z8700
37.5 -2%
Intel Celeron N2830
37.57 -2%
Intel Celeron N3060
37.75 -2%
Intel Pentium N3520
38.33
Intel Celeron N2840
38.67 1%
Intel Core 2 Duo SU7300
38.7 1%
Intel Atom x7-Z8750
38.9 1%
Intel Pentium 2129Y
39 2%
Intel Pentium N3530
39.5 3%
Intel Pentium N3710
40.67 6%
Intel Atom x7-E3950
41 7%
Intel Pentium N3540
41.88 9%
AMD A6-5200
42.45 11%
...
AMD Ryzen 9 7945HX3D
311 711%
max:
Intel Core Ultra 9 285K
355.5 827%
0%
100%
Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
min: 1.75     avg: 1.8     median: 1.8 (2%)     max: 1.77 Points
+ 4 benchmarks and specifications   + Show comparison chart
Cinebench R11.5 - Cinebench R11.5 CPU Single 64 Bit
min: 0.44     avg: 0.4     median: 0.4 (10%)     max: 0.45 Points
+ 4 benchmarks and specifications   + Show comparison chart
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
min: 1250     avg: 1252     median: 1252 (8%)     max: 1254 points
+ 2 benchmarks and specifications   + Show comparison chart
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
min: 4302     avg: 4328     median: 4327.5 (3%)     max: 4353 points
+ 2 benchmarks and specifications   + Show comparison chart
Cinebench R10 - Cinebench R10 Rend. Multi (64bit)
min: 6034     avg: 6142     median: 6142 (4%)     max: 6250 Points
+ 2 benchmarks and specifications   + Show comparison chart
Cinebench R10 - Cinebench R10 Rend. Single (64bit)
min: 1687     avg: 1729     median: 1729 (2%)     max: 1771 Points
+ 2 benchmarks and specifications   + Show comparison chart
wPrime 2.10 - wPrime 2.0 1024m *
min: 867     avg: 870     median: 870 (10%)     max: 873 s
+ 2 benchmarks and specifications   + Show comparison chart
wPrime 2.10 - wPrime 2.0 32m *
min: 26.47     avg: 28     median: 28 (6%)     max: 29.52 s
+ 2 benchmarks and specifications   + Show comparison chart
WinRAR - WinRAR 4.0
min: 1167     avg: 1204     median: 1203.5 (2%)     max: 1240 points
+ 2 benchmarks and specifications   + Show comparison chart
X264 HD Benchmark 4.0 - x264 Pass 2
min: 10.1     avg: 10.2     median: 10.2 (3%)     max: 10.21 fps
+ 2 benchmarks and specifications   + Show comparison chart
X264 HD Benchmark 4.0 - x264 Pass 1
min: 50.5     avg: 50.9     median: 50.9 (12%)     max: 51.3 fps
+ 2 benchmarks and specifications   + Show comparison chart
TrueCrypt - TrueCrypt Serpent
min: 0.0885     avg: 0.1     median: 0.1 (3%)     max: 0.131 GB/s
+ 2 benchmarks and specifications   + Show comparison chart
TrueCrypt - TrueCrypt Twofish
0.2 GB/s (4%)
+ 2 benchmarks and specifications   + Show comparison chart
TrueCrypt - TrueCrypt AES
min: 0.258     avg: 0.3     median: 0.3 (1%)     max: 0.265 GB/s
+ 2 benchmarks and specifications   + Show comparison chart
3DMark 06 - CPU - 3DMark 06 - CPU
min: 2268     avg: 2320     median: 2320 (5%)     max: 2372 Points
+ 2 benchmarks and specifications   + Show comparison chart
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
min: 35.08     avg: 35.4     median: 35.4 (8%)     max: 35.65 s
+ 2 benchmarks and specifications   + Show comparison chart
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
min: 76.9     avg: 77.4     median: 77.4 (3%)     max: 77.9 s
+ 2 benchmarks and specifications   + Show comparison chart
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
min: 1650     avg: 1659     median: 1658.5 (7%)     max: 1667 s
+ 2 benchmarks and specifications   + Show comparison chart
3DMark Vantage - 3DM Vant. Perf. CPU no Physx
4963 Points (4%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark 11 - 3DM11 Performance Physics
min: 1757     avg: 1843     median: 1794 (5%)     max: 1977 Points
+ 3 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Ice Storm Physics
min: 18318     avg: 19789     median: 20148.5 (16%)     max: 20542 Points
+ 4 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Cloud Gate Physics
min: 1267     avg: 1562     median: 1695 (4%)     max: 1724 Points
+ 3 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Fire Strike Standard Physics
2467 Points (4%)
+ 1 benchmarks and specifications   + Show comparison chart
Geekbench 3 - Geekbench 3 32 Bit Multi-Core
2940 points (5%)
+ 1 benchmarks and specifications   + Show comparison chart
Geekbench 3 - Geekbench 3 32 Bit Single-Core
918 points (18%)
+ 1 benchmarks and specifications   + Show comparison chart
Geekbench 2 - 32 Bit - Geekbench Stream
2593 Points (21%)
+ 1 benchmarks and specifications   + Show comparison chart
Geekbench 2 - 32 Bit - Geekbench Memory
2363 Points (21%)
+ 1 benchmarks and specifications   + Show comparison chart
Geekbench 2 - 32 Bit - Geekbench Floating Point
3299 Points (6%)
+ 1 benchmarks and specifications   + Show comparison chart
Geekbench 2 - 32 Bit - Geekbench Integer
3812 Points (8%)
+ 1 benchmarks and specifications   + Show comparison chart
Geekbench 2 - 32 Bit - Geekbench Total Score
3220 Points (8%)
+ 1 benchmarks and specifications   + Show comparison chart
Mozilla Kraken 1.1 - Kraken 1.1 Total Score *
7730 ms (9%)
+ 1 benchmarks and specifications   + Show comparison chart
Sunspider - Sunspider 1.0 Total Score *
368.5 ms (4%)
+ 1 benchmarks and specifications   + Show comparison chart
Octane V2 - Octane V2 Total Score
3551 Points (3%)
+ 1 benchmarks and specifications   + Show comparison chart
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance
