Intel Core 5 120U

Intel Core 5 120U

英特尔酷睿 5 120U是一款中端笔记本 CPU，基于 2024 年 1 月推出的 Raptor Lake-U Refresh（RPL-U）系列（Alder Lake 架构）。该 CPU提供 2 个性能核心（P 核心，Golden Cove 架构）和 8 个效率核心（E 核心，Gracemont 架构）。P 核心支持超线程（因此可同时运行 12 个线程），主频为 1.4 至 5 GHz。E 核心的时钟频率为 0.9 - 3.8 GHz，其性能应与旧版 Skylake 核心（如：i7-6300HQ）相当。 i7-6300HQ).C5 120U 还支持vPro Essentials 管理功能。

性能

由于采用了高时钟频率，其性能可与旧的 酷睿 i7-1355U.与 Alder Lake 处理器一样，性能在很大程度上取决于散热和 TDP 设置。

图形单元

与前代产品一样，英特尔在 Alder Lake 中集成了基于英特尔 Xe 的图形处理器。在 120U 上，96 个 EU 中的 80 个被激活。

功能

与Tiger Lake 一样，Alder-Lake-P 也部分集成了 WiFi 6E 和 Thunderbolt 4（4x）。集成内存控制器支持 LPDDR5-6400，集成的高斯和神经加速器（GNA）安装了 3.0 版本。Quick Sync 8 媒体引擎与 Rocket Lake 相同，支持 MPEG-2、AVC、VC-1 解码、JPEG、VP8 解码、VP9、HEVC 和 AV1 解码。芯片仍然只支持 PCIe 4.0（x8 用于 GPU，两个 x4 用于 SSD）。

功耗

英特尔酷睿 5 120U 的指定 TDP 为 15 瓦（PL1），最大涡轮功率为 55 瓦（PL2）。该处理器采用进一步改进的英特尔 7 处理器（10 纳米 SuperFin）制造。

SeriesIntel Raptor Lake-U
CodenameRaptor Lake-U Refresh

Series: Raptor Lake-U Raptor Lake-U Refresh

Intel Core 7 150U1.2 - 5.4 GHz10 / 12 cores12 MB L3
Intel Core 5 120U « 0.9 - 5 GHz10 / 12 cores12 MB L3
Intel Core 3 100U0.9 - 4.7 GHz6 / 8 cores10 MB L3
Clock Rate900 - 5000 MHz
Level 1 Cache928 KB
Level 2 Cache9.5 MB
Level 3 Cache12 MB
Number of Cores / Threads10 / 12
2 x 5.0 GHz Intel Golden Cove P-Core
8 x 3.8 GHz Intel Gracemont E-Core
Power Consumption (TDP = Thermal Design Power)15 Watt
TDP Turbo PL255 Watt
Manufacturing Technology10 nm
Max. Temperature100 °C
SocketBGA1700
FeaturesThread Director
GPUIntel Iris Xe Graphics G7 80EUs ( - 1250 MHz)
64 Bit64 Bit support
Architecturex86
Announcement Date01/09/2024
Product Link (external)ark.intel.com

Benchmarks

Performance Rating - CB R15 + R20 + 7-Zip + X265 + Blender + 3DM11 CPU
37.1 pt (62%)
AMD E1-2100
2.31 -94%
...
Intel Core Ultra 7 258V
36.5 -2%
Intel Core i5-12500H
36.5 -2%
Intel Core i7-1355U
36.5 -2%
AMD Ryzen 5 PRO 7640HS
36.5 -2%
AMD Ryzen 7 7735HS
36.6 -1%
AMD Ryzen 9 6900HS
36.7 -1%
AMD Ryzen 9 6900HX
36.9 -1%
Intel Core 7 150U
37.1 0%
Intel Core i7-12650H
37.1 0%
Intel Core 5 120U
37.1
AMD Ryzen 5 7540U
37.3 1%
Intel Core Ultra 7 155H
37.5 1%
Intel Core Ultra 7 165H
37.6 1%
Intel Core i7-1360P
37.6 1%
Intel Core i5-13500H
37.6 1%
AMD Ryzen 7 8840U
37.7 2%
Intel Core i9-13905H
37.7 2%
Intel Core i7-1365U
37.7 2%
Intel Core i5-13450HX
37.8 2%
...
AMD Ryzen 9 7945HX3D
47.4 28%
max:
AMD Ryzen Threadripper PRO 7995WX
60.1 62%
0%
100%
Cinebench 2024 - Cinebench 2024 CPU Multi Core
421 Points (8%)
+ 1 benchmarks and specifications   + Show comparison chart
Cinebench R23 - Cinebench R23 Multi Core
7862 Points (7%)
+ 1 benchmarks and specifications   - Hide comparison chart
AMD E1-2100
202 -97%
...
AMD Ryzen 7 4700U
7102 -10%
Intel Core i5-10500H
7104 -10%
Intel Core i7-10750H
7129 -9%
AMD Ryzen 5 5500U
7209 -8%
Intel Core i7-1250U
7275 -7%
Intel Core i5-1250P
7282 -7%
Intel Core i7-1265U
7486 -5%
AMD Ryzen 5 5560U
7667 -2%
Apple M1
7728 -2%
Intel Core 5 120U
7862
AMD Ryzen 5 PRO 5675U
7867 0%
Intel Core i5-1240U
7902 1%
Intel Core i7-1260U
7913 1%
AMD Ryzen 5 5600U
7929 1%
Intel Core i7-1255U
7996 2%
Intel Core i7-10875H
8108 3%
Intel Core i5-11400H
8150 4%
AMD Ryzen 5 4600H
8161 4%
Intel Core i5-1245U
8199 4%
...
AMD Ryzen 9 7945HX3D
32782 317%
max:
AMD Ryzen Threadripper PRO 7995WX
107681 1270%
0%
100%
Cinebench R23 - Cinebench R23 Single Core
1844 Points (78%)
+ 1 benchmarks and specifications   - Hide comparison chart
Cinebench R20 - Cinebench R20 CPU (Single Core)
714 Points (79%)
+ 1 benchmarks and specifications   + Show comparison chart
Cinebench R20 - Cinebench R20 CPU (Multi Core)
3046 Points (7%)
+ 1 benchmarks and specifications   + Show comparison chart
Cinebench R15 - Cinebench R15 CPU Multi 64 Bit
1432 Points (9%)
+ 1 benchmarks and specifications   - Hide comparison chart
075150225300375450525600675750825900975105011251200127513501425Tooltip
Cinebench R15 - Cinebench R15 CPU Single 64 Bit
257 Points (72%)
+ 1 benchmarks and specifications   - Hide comparison chart
7-Zip 18.03 - 7-Zip 18.03 Multi Thread 4 runs
33657 MIPS (19%)
+ 1 benchmarks and specifications   + Show comparison chart
7-Zip 18.03 - 7-Zip 18.03 Single Thread 4 runs
5882 MIPS (69%)
+ 1 benchmarks and specifications   + Show comparison chart
HWBOT x265 Benchmark v2.2 - HWBOT x265 4k Preset
8.7 fps (15%)
+ 1 benchmarks and specifications   + Show comparison chart
05101520Tooltip
Blender - Blender 3.3 Classroom CPU *
816 Seconds (10%)
+ 1 benchmarks and specifications   + Show comparison chart
Blender - Blender 2.79 BMW27 CPU *
437 Seconds (3%)
+ 1 benchmarks and specifications   + Show comparison chart
R Benchmark 2.5 - R Benchmark 2.5 *
0.5 sec (10%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark 11 - 3DM11 Performance Physics
11497 Points (29%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Cloud Gate Physics
9548 Points (24%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Fire Strike Standard Physics
15732 Points (28%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Time Spy CPU
5203 Points (22%)
+ 1 benchmarks and specifications   + Show comparison chart
Geekbench 6.3 - Geekbench 6.3 Single-Core
2570 points (65%)
+ 1 benchmarks and specifications   + Show comparison chart
Geekbench 6.3 - Geekbench 6.3 Multi-Core
9733 points (38%)
+ 1 benchmarks and specifications   - Hide comparison chart
Geekbench 5.5 - Geekbench 5.1 - 5.5 64 Bit Single-Core
1858 points (73%)
+ 1 benchmarks and specifications   + Show comparison chart
Geekbench 5.5 - Geekbench 5.1 - 5.5 64 Bit Multi-Core
8576 points (15%)
+ 1 benchmarks and specifications   + Show comparison chart
Mozilla Kraken 1.1 - Kraken 1.1 Total Score *
502 ms (1%)
+ 1 benchmarks and specifications   + Show comparison chart
WebXPRT 4 - WebXPRT 4 Score
264 Points (74%)
+ 1 benchmarks and specifications   + Show comparison chart
WebXPRT 3 - WebXPRT 3 Score
291 Points (53%)
+ 1 benchmarks and specifications   + Show comparison chart
CrossMark - CrossMark Overall
1671 Points (64%)
+ 1 benchmarks and specifications   + Show comparison chart
Power Consumption - Prime95 Power Consumption - external Monitor *
41.8 Watt (7%)
+ 1 benchmarks and specifications   + Show comparison chart
0510152025303540455055606570Tooltip
Power Consumption - Cinebench R15 Multi Power Consumption - external Monitor *
40.9 Watt (7%)
+ 1 benchmarks and specifications   + Show comparison chart
0510152025303540455055606570Tooltip
Power Consumption - Idle Power Consumption - external Monitor *
4.1 Watt (3%)
+ 1 benchmarks and specifications   + Show comparison chart
012345678910111213Tooltip
Power Consumption - Idle Power Consumption 150cd 1min *
5.1 Watt (6%)
+ 1 benchmarks and specifications   + Show comparison chart
01234567Tooltip
Power Consumption - Cinebench R15 Multi Power Efficiency - external Monitor
35 Points per Watt (26%)
+ 1 benchmarks and specifications   + Show comparison chart
- Range of benchmark values for this graphics card
red legend - Average benchmark values for this graphics card
* Smaller numbers mean a higher performance
