Intel Core i7-1180G7

英特尔酷睿i7-1180G7是基于2021年初推出的Tiger Lake-U Generation (UP4)的笔记本电脑和Ultra Book的能效四核SoC。 4个Willow Cove处理器内核（Hyper-Threading支持8个线程）。保证的基本时钟速度因TDP设定而异，范围为0.9（7WTDP）~2.2GHz（15WTDP）。涡轮时钟速度为1个核心4.6GHz，所有核心最高可达3.7GHz。

此外，基于全新Gen 12体系结构的集成Xe显卡和96EU。与以前的Iris Plus G7（冰湖）相比，性能显著提高。 GPU 和 CPU 可以同时使用 12 MB 的 L3 高速缓存。

此外，Tiger Lake SoCs还添加了PCIe 4支持（4通道）、AI硬件加速、Thunderbolt 4/USB 4和Wi-Fi 6的部分集成到芯片中。 i5-1140G7还支持管理功能博锐。

此芯片在英特尔改进的 10nm 工艺（称为 SuperFin）中生产，与 TSMC 的 7nm 工艺（例如，Ryzen 4000 系列）相同。

UP4系列的动作范围为7~是15瓦特。因此，处理器非常适合超薄、轻巧的笔记本电脑、敞篷和平板电脑。

Series

Intel Tiger Lake

Codename

Tiger Lake-UP4

Series: Tiger Lake Tiger Lake-UP4

Intel Core i7-1180G7 «	2.2 - 4.6 GHz	4 / 8	12 MB L3
Intel Core i7-1160G7	2.1 - 4.4 GHz	4 / 8	12 MB L3
Intel Core i5-1140G7	1.8 - 4.2 GHz	4 / 8	8 MB L3
Intel Core i5-1130G7	1.8 - 4 GHz	4 / 8	8 MB L3
Intel Core i3-1120G4	1.5 - 3.5 GHz	4 / 8	8 MB L3
Intel Core i3-1110G4	2.5 - 3.9 GHz	2 / 4	6 MB L3

Clock Rate

2200 - 4600 MHz

Level 1 Cache

320 KB

Level 2 Cache

5 MB

Level 3 Cache

12 MB

Number of Cores / Threads

4 / 8

Power Consumption (TDP = Thermal Design Power)

15 Watt

Manufacturing Technology

10 nm

Max. Temperature

100 °C

Socket

BGA1598

Features

DL Boost, GNA, Wi-Fi 6 (Gig+), Thunderbolt 4, LPDDR4x-4266

GPU

Intel Iris Xe Graphics G7 96EUs (400 - 1100 MHz)

64 Bit

64 Bit support

Architecture

x86

Announcement Date

09/02/2020

Product Link (external)

ark.intel.com

Benchmarks

Performance Rating - CB R15 + R20 + 7-Zip + X265 + Blender + 3DM11 CPU

29.8 pt (50%)

AMD E1-2100

2.31 -92%

...

AMD Ryzen 5 PRO 4650U

28.9 -3%

Intel Core i3-1115G4

29.1 -2%

Intel Core i7-10710U

29.2 -2%

AMD Ryzen 5 5500U

29.2 -2%

AMD Ryzen 7 4700U

29.3 -2%

Intel Core i7-8850H

29.4 -1%

AMD Ryzen 5 4600H

29.5 -1%

Intel Core i5-10300H

29.7 0%

Intel Core i5-10400H

29.8 0%

Intel Core i7-1180G7

29.8

Intel Core i5-1250P

29.9 0%

AMD Ryzen 7 PRO 4750U

29.9 0%

Intel Core i7-9750H

29.9 0%

Qualcomm Snapdragon X Plus X1P-42-100

29.9 0%

30.1 1%

30.2 1%

30.2 1%

30.3 2%

Intel Core i7-8559U

30.4 2%

...

AMD Ryzen 9 7945HX3D

47.4 59%

max:

AMD Ryzen Threadripper PRO 7995WX

60.1 102%

100%

Cinebench R23 - Cinebench R23 Multi Core

3434 Points (3%)

+ 1 benchmarks and specifications - Hide comparison chart

Model	CPU	GPU	RAM	Value
Dell Latitude 13 7320 Detachable, i7-1180G7	i7-1180G7 40 W / 23 W	Iris Xe G7 96EUs 1100 / 1600 MHz	16 GB	3434

AMD E1-2100

202 -94%

...

Intel Processor N97

2913 -15%

Intel Core i7-8550U

2914 -15%

AMD Ryzen 5 3450U

2927 -15%

Intel Core i5-8260U

3028 -12%

Intel Core i3-1115G4

3038 -12%

Intel Core i5-10310U

3094 -10%

Intel Core i5-8250U

3108 -9%

AMD Ryzen Embedded V1605B

3160 -8%

Intel Core i5-10210U

3321 -3%

Intel Core i7-1180G7

3434

Intel Core i5-8265U

3500 2%

AMD Ryzen 3 4300U

3571 4%

Qualcomm Snapdragon 8cx Gen 3

3603 5%

AMD Ryzen 7 2700U

3603 5%

Intel Core i7-1065G7

3615 5%

Intel Core i5-8259U

3792 10%

Intel Core i5-1035G4

3800 11%

Intel Core i7-10510U

3866 13%

AMD Ryzen 7 3750H

3897 13%

...

AMD Ryzen 9 7945HX3D

32782 855%

max:

AMD Ryzen Threadripper PRO 7995WX

107681 3036%

100%

Cinebench R23 - Cinebench R23 Single Core

1280 Points (54%)

+ 1 benchmarks and specifications - Hide comparison chart

Model	CPU	GPU	RAM	Value
Dell Latitude 13 7320 Detachable, i7-1180G7	i7-1180G7 40 W / 23 W	Iris Xe G7 96EUs 1100 / 1600 MHz	16 GB	1280

AMD A10-5745M

74.4 -94%

...

1223 -4%

1232 -4%

1235 -4%

1246 -3%

1254 -2%

1254 -2%

1260 -2%

AMD Ryzen 5 5560U

1260 -2%

Intel Core i9-10980HK

1277 0%

Intel Core i7-1180G7

1280

Intel Core i9-10885H

1290 1%

AMD Ryzen 9 4900H

1294 1%

Qualcomm Snapdragon X Elite X1E-80-100

1296 1%

Intel Core i3-1115G4

1299 1%

Intel Xeon W-10885M

1300 2%

Intel Core i5-1230U

1319 3%

Intel Core i5-1135G7

1322 3%

AMD Ryzen 3 5425U

1332 4%

AMD Ryzen 7 PRO 7735U

1345 5%

...

Apple M4 (10 cores)

2269 77%

max:

Intel Core Ultra 9 285K

2348 83%

100%

Cinebench R20 - Cinebench R20 CPU (Single Core)

492 Points (55%)

+ 1 benchmarks and specifications + Show comparison chart

Model	CPU	GPU	RAM	Value
Dell Latitude 13 7320 Detachable, i7-1180G7	i7-1180G7 40 W / 23 W	Iris Xe G7 96EUs 1100 / 1600 MHz	16 GB	492

Cinebench R20 - Cinebench R20 CPU (Multi Core)

1301 Points (3%)

+ 1 benchmarks and specifications + Show comparison chart

Model	CPU	GPU	RAM	Value
Dell Latitude 13 7320 Detachable, i7-1180G7	i7-1180G7 40 W / 23 W	Iris Xe G7 96EUs 1100 / 1600 MHz	16 GB	1301

Cinebench R15 - Cinebench R15 CPU Multi 64 Bit

549 Points (3%)

+ 1 benchmarks and specifications - Hide comparison chart

Model	CPU	GPU	RAM	Value
Dell Latitude 13 7320 Detachable, i7-1180G7	i7-1180G7 40 W / 23 W	Iris Xe G7 96EUs 1100 / 1600 MHz	16 GB	549

AMD A4-1200

31 -94%

...

Intel Processor N97

479 -13%

AMD Ryzen 3 PRO 3300U

481 -12%

Intel Core i7-4702HQ

501 -9%

Intel Core i5-6440HQ

510 -7%

Intel Core i5-7300HQ

512 -7%

Intel Core i7-4712HQ

518 -6%

Intel Core i7-3632QM

521 -5%

Intel Core i7-2860QM

533 -3%

Intel Core i5-8350U

548 0%

Intel Core i7-1180G7

549

Intel Core i5-7440HQ

554 1%

Intel Core i7-4702MQ

555 1%

AMD Ryzen 5 PRO 2500U

561 2%

563 3%

567 3%

570 4%

576 5%

Intel Core i7-4850HQ

578 5%

Intel Core i5-8365U

584 6%

...

AMD Ryzen 9 7945HX3D

5600 920%

max:

AMD Ryzen Threadripper PRO 7995WX

15842 2786%

100%

show legend

Cinebench R15 - Cinebench R15 CPU Single 64 Bit

188 Points (53%)

+ 1 benchmarks and specifications - Hide comparison chart

Model	CPU	GPU	RAM	Value
Dell Latitude 13 7320 Detachable, i7-1180G7	i7-1180G7 40 W / 23 W	Iris Xe G7 96EUs 1100 / 1600 MHz	16 GB	188

AMD A4-1200

19 -90%

...

Intel Core i7-8850H

180.4 -4%

AMD Ryzen 7 PRO 4750U

181.4 -4%

Intel Xeon E-2176M

181.7 -3%

AMD Ryzen 7 4980U

182 -3%

Intel Core i7-9750H

183.7 -2%

184 -2%

186.3 -1%

186.5 -1%

187.5 0%

Intel Core i7-1180G7

188

190.1 1%

192 2%

193 3%

193 3%

193.8 3%

194.4 3%

194.8 4%

Intel Xeon E-2276M

195 4%

Intel Core i9-8950HK

195.9 4%

...

AMD Ryzen 9 7945HX3D

311 65%

max:

Intel Core Ultra 9 285K

355.5 89%

100%

7-Zip 18.03 - 7-Zip 18.03 Multi Thread 4 runs

19703 MIPS (11%)

+ 1 benchmarks and specifications + Show comparison chart

Model	CPU	GPU	RAM	Value
Dell Latitude 13 7320 Detachable, i7-1180G7	i7-1180G7 40 W / 23 W	Iris Xe G7 96EUs 1100 / 1600 MHz	16 GB	19703

7-Zip 18.03 - 7-Zip 18.03 Single Thread 4 runs

5108 MIPS (60%)

+ 1 benchmarks and specifications + Show comparison chart

Model	CPU	GPU	RAM	Value
Dell Latitude 13 7320 Detachable, i7-1180G7	i7-1180G7 40 W / 23 W	Iris Xe G7 96EUs 1100 / 1600 MHz	16 GB	5108

HWBOT x265 Benchmark v2.2 - HWBOT x265 4k Preset

4.7 fps (8%)

+ 1 benchmarks and specifications + Show comparison chart

Model	CPU	GPU	RAM	Value
Dell Latitude 13 7320 Detachable, i7-1180G7	i7-1180G7 40 W / 23 W	Iris Xe G7 96EUs 1100 / 1600 MHz	16 GB	4.7

show legend

Blender - Blender 2.79 BMW27 CPU *

844 Seconds (6%)

+ 1 benchmarks and specifications + Show comparison chart

Model	CPU	GPU	RAM	Value
Dell Latitude 13 7320 Detachable, i7-1180G7	i7-1180G7 40 W / 23 W	Iris Xe G7 96EUs 1100 / 1600 MHz	16 GB	844

R Benchmark 2.5 - R Benchmark 2.5 *

0.6 sec (14%)

+ 1 benchmarks and specifications + Show comparison chart

Model	CPU	GPU	RAM	Value
Dell Latitude 13 7320 Detachable, i7-1180G7	i7-1180G7 40 W / 23 W	Iris Xe G7 96EUs 1100 / 1600 MHz	16 GB	0.646

3DMark 11 - 3DM11 Performance Physics

6916 Points (17%)

+ 1 benchmarks and specifications + Show comparison chart

Model	CPU	GPU	RAM	Value
Dell Latitude 13 7320 Detachable, i7-1180G7	i7-1180G7 40 W / 23 W	Iris Xe G7 96EUs 1100 / 1600 MHz	16 GB	6916

3DMark - 3DMark Cloud Gate Physics

5217 Points (13%)

+ 1 benchmarks and specifications + Show comparison chart

Model	CPU	GPU	RAM	Value
Dell Latitude 13 7320 Detachable, i7-1180G7	i7-1180G7 40 W / 23 W	Iris Xe G7 96EUs 1100 / 1600 MHz	16 GB	5217

3DMark - 3DMark Fire Strike Standard Physics

8552 Points (15%)

+ 1 benchmarks and specifications + Show comparison chart

Model	CPU	GPU	RAM	Value
Dell Latitude 13 7320 Detachable, i7-1180G7	i7-1180G7 40 W / 23 W	Iris Xe G7 96EUs 1100 / 1600 MHz	16 GB	8552

3DMark - 3DMark Time Spy CPU

2966 Points (13%)

+ 1 benchmarks and specifications + Show comparison chart

Model	CPU	GPU	RAM	Value
Dell Latitude 13 7320 Detachable, i7-1180G7	i7-1180G7 40 W / 23 W	Iris Xe G7 96EUs 1100 / 1600 MHz	16 GB	2966

Geekbench 5.5 - Geekbench 5.1 - 5.5 64 Bit Single-Core

1525 points (60%)

+ 1 benchmarks and specifications - Hide comparison chart

Model	CPU	GPU	RAM	Value
Dell Latitude 13 7320 Detachable, i7-1180G7	i7-1180G7 40 W / 23 W	Iris Xe G7 96EUs 1100 / 1600 MHz	16 GB	1525

AMD E1-2100

125 -92%

...

1493 -2%

1497 -2%

1507 -1%

1511 -1%

1520 0%

1520 0%

1522 0%

Intel Core Ultra 7 164U

1522 0%

Intel Core i7-1165G7

1524 0%

Intel Core i7-1180G7

1525

Intel Core i5-1240P

1527 0%

AMD Ryzen 9 5980HS

1537 1%

1539 1%

1540 1%

1541 1%

1541 1%

Intel Core i5-1230U

1541 1%

AMD Ryzen 9 PRO 6950HS

1549 2%

AMD Ryzen 7 6800H

1550 2%

...

Apple M3 Pro 11-Core

2331 53%

max:

AMD Ryzen 9 9900X

2544 67%

100%

Geekbench 5.5 - Geekbench 5.1 - 5.5 64 Bit Multi-Core

5304 points (10%)

+ 1 benchmarks and specifications + Show comparison chart

Model	CPU	GPU	RAM	Value
Dell Latitude 13 7320 Detachable, i7-1180G7	i7-1180G7 40 W / 23 W	Iris Xe G7 96EUs 1100 / 1600 MHz	16 GB	5304

Geekbench 5.0 - Geekbench 5.0 64 Bit Single-Core

1530 points (7%)

+ 1 benchmarks and specifications + Show comparison chart

Model	CPU	GPU	RAM	Value
Dell Latitude 13 7320 Detachable, i7-1180G7	i7-1180G7 40 W / 23 W	Iris Xe G7 96EUs 1100 / 1600 MHz	16 GB	1530

Geekbench 5.0 - Geekbench 5.0 64 Bit Multi-Core

5254 points (17%)

+ 1 benchmarks and specifications + Show comparison chart

Model	CPU	GPU	RAM	Value
Dell Latitude 13 7320 Detachable, i7-1180G7	i7-1180G7 40 W / 23 W	Iris Xe G7 96EUs 1100 / 1600 MHz	16 GB	5254

Geekbench 4.4 - Geekbench 4.1 - 4.4 64 Bit Single-Core

6260 points (63%)

+ 1 benchmarks and specifications + Show comparison chart

Model	CPU	GPU	RAM	Value
Dell Latitude 13 7320 Detachable, i7-1180G7	i7-1180G7 40 W / 23 W	Iris Xe G7 96EUs 1100 / 1600 MHz	16 GB	6260

Geekbench 4.4 - Geekbench 4.1 - 4.4 64 Bit Multi-Core

19898 points (20%)

+ 1 benchmarks and specifications + Show comparison chart

Model	CPU	GPU	RAM	Value
Dell Latitude 13 7320 Detachable, i7-1180G7	i7-1180G7 40 W / 23 W	Iris Xe G7 96EUs 1100 / 1600 MHz	16 GB	19898

Mozilla Kraken 1.1 - Kraken 1.1 Total Score *

662 ms (1%)

+ 1 benchmarks and specifications + Show comparison chart

Model	CPU	GPU	RAM	Value
Dell Latitude 13 7320 Detachable, i7-1180G7	i7-1180G7 40 W / 23 W	Iris Xe G7 96EUs 1100 / 1600 MHz Chrome 82	16 GB	662

WebXPRT 3 - WebXPRT 3 Score

242 Points (44%)

+ 1 benchmarks and specifications + Show comparison chart

Model	CPU	GPU	RAM	Value
Dell Latitude 13 7320 Detachable, i7-1180G7	i7-1180G7 40 W / 23 W	Iris Xe G7 96EUs 1100 / 1600 MHz Chrome 82	16 GB	242

Power Consumption - Prime95 Power Consumption - external Monitor *

29.3 Watt (5%)

+ 1 benchmarks and specifications + Show comparison chart

Model	CPU	GPU	RAM	Value
Dell Latitude 13 7320 Detachable, i7-1180G7	i7-1180G7 40 W / 23 W	Iris Xe G7 96EUs 1100 / 1600 MHz	16 GB	29.3

show legend

Power Consumption - Cinebench R15 Multi Power Consumption - external Monitor *

42.9 Watt (8%)

+ 1 benchmarks and specifications + Show comparison chart

Model	CPU	GPU	RAM	Value
Dell Latitude 13 7320 Detachable, i7-1180G7	i7-1180G7 40 W / 23 W	Iris Xe G7 96EUs 1100 / 1600 MHz	16 GB	42.9

show legend

Power Consumption - Cinebench R15 Multi Power Efficiency - external Monitor

12.8 Points per Watt (10%)

+ 1 benchmarks and specifications + Show comparison chart

Model	CPU	GPU	RAM	Value
Dell Latitude 13 7320 Detachable, i7-1180G7	i7-1180G7 40 W / 23 W	Iris Xe G7 96EUs 1100 / 1600 MHz	16 GB	12.8

- Range of benchmark values for this graphics card

- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance

v1.28

log 17. 02:50:15

#0 ran 0s before starting gpusingle class +0s ... 0s

#1 no ids found in url (should be separated by "_") +0s ... 0s

#2 not redirecting to Ajax server +0s ... 0s

#3 did not recreate cache, as it is less than 5 days old! Created at Sat, 16 Nov 2024 05:31:01 +0100 +0.001s ... 0.001s

#4 no comparison url found in template nbc.compare_page_2 needed +0.007s ... 0.008s

#5 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.008s

#6 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.008s

#7 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.008s

#8 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.009s

#9 composed specs +0s ... 0.009s

#10 did output specs +0s ... 0.009s

#11 getting avg benchmarks for device 12730 +0.016s ... 0.025s

#12 got single benchmarks 12730 +0.008s ... 0.033s

#13 got avg benchmarks for devices +0s ... 0.033s

#14 min, max, avg, median took s +0.499s ... 0.532s

#15 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.532s

#16 return log +0s ... 0.532s

Reviews for the Intel Core i7-1180G7 processor

Lenovo ThinkPad X1 Nano-20UN0058US: Intel Iris Xe Graphics G7 96EUs, 13.00", 0.9 kg
External Review » Lenovo ThinkPad X1 Nano-20UN0058US

Lenovo ThinkPad X1 Titanium Yoga G1 20QB0018GE: Intel Iris Xe Graphics G7 96EUs, 13.50", 1.2 kg
External Review » Lenovo ThinkPad X1 Titanium Yoga G1 20QB0018GE

Dell Latitude 13 7320 Detachable, i7-1180G7: Intel Iris Xe Graphics G7 96EUs, 13.00", 0.8 kg
External Review » Dell Latitude 13 7320 Detachable, i5-1135G7

Please share our article, every link counts!

»移动处理器对比
所有移动处理器的对比

»移动处理器基准测试
所有已有笔记本电脑中使用的处理器的基准测试成绩 (桌面处理器或移动处理器)

Other CPUs of the series Tiger Lake

» Intel Core i9-11900KB
8x 3.3 GHz - 5.3 GHz

» Intel Core i9-11980HK
8x 3.3 GHz - 5 GHz

» Intel Core i9-11900H
8x 2.5 GHz - 4.9 GHz

» Intel Core i9-11950H
8x 2.6 GHz - 5 GHz

» Intel Xeon W-11955M
8x 2.6 GHz - 5 GHz

» Intel Core i7-11850H
8x 2.5 GHz - 4.8 GHz

» Intel Core i7-11800H
8x 2.3 GHz - 4.6 GHz

» Intel Core i7-11600H
6x 2.9 GHz - 4.6 GHz

» Intel Xeon W-11855M
6x 3.2 GHz - 4.9 GHz

» Intel Core i5-11500H
6x 2.9 GHz - 4.6 GHz

» Intel Core i5-11500B
6x 3.3 GHz - 4.6 GHz

» Intel Core i5-11400H
6x 2.7 GHz - 4.5 GHz

» Intel Core i5-11260H
6x 2.6 GHz - 4.4 GHz

» Intel Core i7-11390H
4x 3.4 GHz - 5 GHz

» Intel Core i7-11375H
4x 3.3 GHz - 5 GHz

» Intel Core i7-1195G7
4x 2.9 GHz - 5 GHz

» Intel Core i7-11370H
4x 3.3 GHz - 4.8 GHz

» Intel Core i7-1185G7
4x 3 GHz - 4.8 GHz

» Intel Core i7-1165G7
4x 2.8 GHz - 4.7 GHz

» Intel Core i5-1155G7
4x 2.5 GHz - 4.5 GHz

» Intel Core i5-11320H
4x 3.2 GHz - 4.5 GHz

» Intel Core i5-11300H
4x 3.1 GHz - 4.4 GHz

» Intel Core i5-1145G7
4x 2.6 GHz - 4.4 GHz

» Intel Core i5-1135G7
4x 2.4 GHz - 4.2 GHz

» Intel Core i7-1180G7
4x 2.2 GHz - 4.6 GHz

» Intel Core i7-1160G7
4x 2.1 GHz - 4.4 GHz

» Intel Core i5-1140G7
4x 1.8 GHz - 4.2 GHz

» Intel Core i5-1130G7
4x 1.8 GHz - 4 GHz

» Intel Core i3-1125G4
4x 2 GHz - 3.7 GHz

» Intel Core i3-1115G4
2x 3 GHz - 4.1 GHz

» Intel Core i3-1120G4
4x 1.5 GHz - 3.5 GHz

» Intel Pentium Gold 7505
2x 2 GHz - 3.5 GHz

» Intel Core i3-1110G4
2x 2.5 GHz - 3.9 GHz

» Intel Celeron 6305
2x 1.8 GHz

» Intel Celeron 6205
2x

Surrounding CPUs

+ Intel Core i5-8400H
4x 2.5 GHz - 4.2 GHz

+ Intel Core i7-8559U
4x 2.7 GHz - 4.5 GHz

+ Intel Xeon E3-1505M v6
4x 3 GHz - 4 GHz

+ Intel Core i5-8300H
4x 2.3 GHz - 4 GHz

+ Intel Xeon E3-1575M v5
4x 3 GHz - 3.9 GHz

» Intel Core i7-1180G7
4x 2.2 GHz - 4.6 GHz

- AMD Ryzen 3 PRO 4450U
4x 2.5 GHz - 3.7 GHz

- Intel Core i7-4940MX
4x 3.1 GHz - 4 GHz

- Intel Core i7-7820HQ
4x 2.9 GHz - 3.9 GHz

- Intel Core i7-7820HK
4x 2.9 GHz - 3.9 GHz

- Intel Core i7-6920HQ
4x 2.9 GHz - 3.8 GHz

> Notebookcheck中文版（NBC中国） > FAQ / 小提示/ 技术参数 > 移动处理器 —— 基准测试成绩列表 > Intel Tiger Lake i7-1180G7 笔记本处理器

Klaus Hinum (Update: 2021-08-13)
