Lenovo ThinkBook 14-IML-20RV00BRIH

Specifications

Lenovo ThinkBook 14-IML-20RV00BRIH
Lenovo ThinkBook 14-IML-20RV00BRIH (ThinkBook 14 Series)
Processor
Intel Core i3-10110U 2 x 2.1 - 4.1 GHz, Comet Lake-U
Graphics adapter
Intel UHD Graphics 620
Memory
4 GB
, DDR4-2666 (onboard)
Display
14.00 inch 16:9, 1920 x 1080 pixel 157 PPI, TN LED, glossy: no
Storage
1TB HDD
Connections
1 USB 2.0, 3 USB 3.0 / 3.1 Gen1, 1 USB 3.1 Gen2, 1 Thunderbolt, 1 HDMI, 1 DisplayPort, Audio Connections: 3.5mm, Card Reader: SD, 1 Fingerprint Reader, USB-C
Networking
10/100/1000 LAN Card (10/100/1000MBit/s), Intel Wireless-AC 9560 (a/b/g/n = Wi-Fi 4/ac = Wi-Fi 5/), Bluetooth 5.0
Size
height x width x depth (in mm): 17.9 x 326 x 230
Battery
45 Wh, 3900 mAh Lithium-Ion, Battery runtime (according to manufacturer): 9 h
Operating System
Microsoft Windows 10 Home 64 Bit
Camera
Webcam: HD 720p
Additional features
Speakers: Stereo, Keyboard: Chiclet, Keyboard Light: no
Weight
1.5 kg
Price
700 Euro
Links
Lenovo homepage



Price comparison

Reviews for the Lenovo ThinkBook 14-IML-20RV00BRIH

Đánh giá chi tiết Lenovo ThinkBook 14: Thời trang đẳng cấp, phong cách thời thượng chuẩn doanh nhân!
Source: The Gioididong VN→zh-CN Archive.org version
Single Review, online available, Very Long, Date: 05/03/2020

Comment

Intel UHD Graphics 620:

集成显卡（GT2,24 EU），可以在一些Kaby-Lake-Refresh 中央处理器型号（15 W ULV系列）上找到。技术上与之前名为HD Graphics 620的Kaby-Lake的显卡相同。



» Further information can be found in our Comparison of Mobile Graphics Cards and the corresponding Benchmark List.


i3-10110U:

基于Comet Lake的低功耗双核处理器（在技术上与Whiskey Lake相同，但仍采用14nm ++生产）。具有超线程（4个线程），CPU频率在2.1和4.1 GHz之间（全核最高频率为3.7 GHz）提供时钟。集成内存控制器支持DDR4-2666，使用cTDP上/下性能可以由OEM调整（可能为10-25瓦，默认为15W）。集成显卡的时钟频率为300-1000 MHz，仅提供23个而不是24个CU。

» Further information can be found in our Comparison of Mobile Processsors.


14.00":

大体上，这个屏幕尺寸常见于亚笔记本电脑，超极本和变形本中。对这三类产品来说这个尺寸都较大。亚笔记本中尺寸最大的机型是采用这个屏幕尺寸。

大尺寸可以让屏幕有更高的分辨率。因而例如字体等的细节将会更丰富。不过另一方面，小屏幕的功耗会较低，而设备也会更轻盈小巧，售价更低。

» To find out how fine a display is, see our DPI List.


1.5 kg: 这是11到13寸的超大尺寸平板电脑，亚笔记本电脑，超极本和变形本的常见重量。


» Further information can be found in our Notebook Purchase Guide.
