Lenovo ThinkPad T560-20FH002RGE

Specifications

Lenovo ThinkPad T560-20FH002RGE
Lenovo ThinkPad T560-20FH002RGE (ThinkPad T560 Series)
Processor
Intel Core i7-6600U 2 x 2.6 - 3.4 GHz, Skylake
Graphics adapter
NVIDIA GeForce 940MX - 2048 MB VRAM, Core: 1242 MHz, RAM: 1000 MHz, DDR3, ForceWare 359.30, Optimus
Memory
8 GB
, 1x 8 GB DDR3L-1600, 1 von 2 Slots belegt
Display
15.60 inch 16:9, 2880 x 1620 pixel 212 PPI, Panasonic VVX16T028J00, IPS, LED-Backlight, glossy: no
Mainboard
Intel Skylake-U Premium PCH
Storage
Samsung SSD PM871 MZ7LN256HCHP, 256 GB
Soundcard
Intel Skylake-U/Y PCH - High Definition Audio
Connections
3 USB 3.0 / 3.1 Gen1, 1 HDMI, 1 DisplayPort, 1 Kensington Lock, 1 Docking Station Port, Audio Connections: Headset-Buchse (3,5 Millimeter Klinke), Card Reader: SD, 1 SmartCard, 1 Fingerprint Reader
Networking
Intel Ethernet Connection I219-LM (10/100/1000MBit/s), Intel Dual Band Wireless-AC 8260 (a/b/g/n = Wi-Fi 4/ac = Wi-Fi 5/), Bluetooth 4.2, 4G/LTE (Huawei ME906s), LTE, GPS
Size
height x width x depth (in mm): 22.4 x 380 x 252
Battery
67 Wh Lithium-Ion, removeable, 44 Wh intern + 23 Wh extern
Operating System
Microsoft Windows 10 Pro 64 Bit
Camera
Webcam: 720p
Additional features
Speakers: Stereo, Keyboard: Chiclet, Keyboard Light: yes, 65-Watt-Netzteil, 36 Months Warranty
Weight
2.25 kg, Power Supply: 340 g
Price
2000 Euro



Price comparison

Average Score: 89% - very good
Average of 1 scores (from 1 reviews)
price: - %, performance: 74%, features: 70%, display: 86% mobility: 76%, workmanship: 90%, ergonomy: 91%, emissions: 91%

Reviews for the Lenovo ThinkPad T560-20FH002RGE

89% Lenovo ThinkPad T560 (Core i7, 940MX, 3K) Notebook Review | Notebookcheck
All of everything! Equipped with a Core i7 processor, 3K display, and dedicated graphics, the T560 aims to take the lead in our business charts. But, is the generous number of features justify a price of almost 2000 Euros (~$2267).
Lenovo Thinkpad T560 – A munkatárs
Source: Laptopkalauz HU→zh-CN Archive.org version
Single Review, online available, Long, Date: 01/16/2018

Comment

NVIDIA GeForce 940MX: 基于Maxwell架构的中端笔记本电脑显卡。相比较老的940M,MX支持GDDR5显存和可能稍快的主频。



» Further information can be found in our Comparison of Mobile Graphics Cards and the corresponding Benchmark List.


6600U: » Further information can be found in our Comparison of Mobile Processsors.


15.60": 15到16寸是笔记本电脑的标准尺寸,产品型号最为丰富。» To find out how fine a display is, see our DPI List.


2.25 kg: 大部分12到16寸的亚笔记本电脑,超极本和轻盈标准笔记本电脑的重量在这个水平上。


» Further information can be found in our Notebook Purchase Guide.
