Lenovo Yoga 510-14IKB-80VB004DGE

Specifications

Lenovo Yoga 510-14IKB-80VB004DGE
Lenovo Yoga 510-14IKB-80VB004DGE (Yoga 510 Series)
Processor
Intel Core i7-7500U 2 x 2.7 - 3.5 GHz, Kaby Lake
Graphics adapter
Memory
8 GB
, DDR4, 2133 MHz Single-Channel
Display
14.00 inch 16:9, 1920 x 1080 pixel 157 PPI, Capacitive, 10-point, BOE0637 / BOE DT NV140FHM-N41, IPS, glossy: yes
Mainboard
Intel Kaby Lake-U Premium PCH
Storage
Samsung MZYTY256HDHP, 256 GB
Soundcard
Intel Kaby Lake-U/Y PCH - High Definition Audio
Connections
1 USB 2.0, 2 USB 3.0 / 3.1 Gen1, 1 HDMI, 1 DisplayPort, 1 Kensington Lock, Audio Connections: 3.5mm combo, Card Reader: SD/SDHC/SDXC/MMC
Networking
Realtek RTL8168/8111 Gigabit-LAN (10/100/1000MBit/s), Qualcomm Atheros QCA9377 Wireless Network Adapter (a/b/g/n = Wi-Fi 4/ac = Wi-Fi 5/), Bluetooth 4.0
Size
height x width x depth (in mm): 20.9 x 336 x 232
Battery
35 Wh Lithium-Polymer
Operating System
Microsoft Windows 10 Home 64 Bit
Camera
Webcam: HD
Additional features
Speakers: Stereo, Keyboard: Chiclet, Keyboard Light: yes
Weight
1.73 kg, Power Supply: 232 g
Price
900 Euro



Price comparison

Average Score: 69% - average
Average of 1 scores (from 3 reviews)
price: - %, performance: 82%, features: 68%, display: 71% mobility: 63%, workmanship: - %, ergonomy: 63%, emissions: - %

Reviews for the Lenovo Yoga 510-14IKB-80VB004DGE

Lenovo Yoga 510
Source: Tech Smart English EN→zh-CN Archive.org version
The Lenovo Yoga 510 can do pretty much everything you need it to. There's a generously sized 14" display that's crisp and clear, as well as a solid body that should stand the test of time. Add to this well specced innards, along with a number of different modes for consumers looking for something a little more quirky, and the Yoga 510 becomes a notebook that is hard to resist.
Single Review, online available, Medium, Date: 12/14/2016
69% Lenovo Yoga 510
Source: Chip.de German DE→zh-CN Archive.org version
Single Review, online available, Medium, Date: 12/16/2016
Rating: Total score: 69% performance: 82% features: 68% display: 71% mobility: 63% ergonomy: 63%
[Análisis] Lenovo Yoga 510-14IKB, un interesante convertible 4 en 1 en rebajas
Source: Mi Mundo Gadget Spanish ES→zh-CN Archive.org version
Single Review, online available, Short, Date: 07/01/2017

Comment

Intel HD Graphics 620:

集成显卡(GT2, 24 EUs)可以在一些Kaby-Lake-Refresh处理器构架(15 W ULV 系列)中找到。而在技术上,与前代 Kaby-Lake集成显卡相同,我们称它为HD Graphics 620.



» Further information can be found in our Comparison of Mobile Graphics Cards and the corresponding Benchmark List.


i7-7500U:

基于Kaby-Lake架构的双核处理器,主频为2.7至3.5 GHz,支持超线程,采用改进的14纳米制程技术制造。

» Further information can be found in our Comparison of Mobile Processsors.


14.00":

大体上,这个屏幕尺寸常见于亚笔记本电脑,超极本和变形本中。对这三类产品来说这个尺寸都较大。亚笔记本中尺寸最大的机型是采用这个屏幕尺寸。

大尺寸可以让屏幕有更高的分辨率。因而例如字体等的细节将会更丰富。不过另一方面,小屏幕的功耗会较低,而设备也会更轻盈小巧,售价更低。

» To find out how fine a display is, see our DPI List.


1.73 kg: 这是11到13寸的超大尺寸平板电脑,亚笔记本电脑,超极本和变形本的常见重量。


» Further information can be found in our Notebook Purchase Guide.
