MSI Stealth 16 AI Studio A1VGG

Specifications

MSI Stealth 16 AI Studio A1VGG
MSI Stealth 16 AI Studio A1VGG (Stealth 16 AI Studio Series)
Processor
Intel Core Ultra 9 185H 16 x 3.8 - 5.1 GHz, Meteor Lake-H
Graphics adapter
NVIDIA GeForce RTX 4070 Laptop GPU - 8 GB VRAM, Core: 1980 MHz, 105 W TDP, GDDR6
Memory
32 GB
, DDR5-5600
Display
16.00 inch 16:10, 2560 x 1600 pixel 189 PPI, IPS, (or 16” UHD+ (3840x2400), 120Hz), glossy: yes, 240 Hz
Storage
M.2 PCIe
Connections
3 USB 3.1 Gen2, 1 Thunderbolt, USB-C Power Delivery (PD), 1 HDMI, 1 Kensington Lock, Audio Connections: 3.5mm, Card Reader: microSD
Networking
10/100/1000 LAN Card (10/100/1000MBit/s), Wi-Fi 7 (a/b/g/n = Wi-Fi 4/ac = Wi-Fi 5/ax = Wi-Fi 6/ Wi-Fi 6E 6 GHz be = Wi-Fi 7), Bluetooth 5.4
Size
height x width x depth (in mm): 19.95 x 355.8 x 259.7
Battery
99.9 Wh, 4-cell
Operating System
Microsoft Windows 11 Home
Camera
Webcam: IR
Primary Camera: 2 MPix
Additional features
Speakers: Stereo, 2x 2W Speaker + 4x 2W Woofer, Keyboard: Chiclet, Keyboard Light: yes
Weight
1.99 kg



Price comparison

Reviews for the MSI Stealth 16 AI Studio A1VGG

微星Stealth 16 AI Studio A1V评测–卓越性能受制于可怕的过热现象
Source: Laptopmedia CN
纤薄坚固的金属机箱,内置强大的硬件–这就是微星 Stealth 16 AI Studio A1V 的最佳写照。配备五根热管和一对风扇的散热系统十分强劲。这就是为什么英特尔酷睿 Ultra 9 185H 可以在长时间负载下将 P 核心和 E 核心的频率提升到 3.20GHz / 2.70GHz 左右,是的,对于这样一款轻薄的笔记本电脑来说,这是一个不错的结果。另一方面,GPU 内存温度过高导致 TGP在 “极致性能 “模式下明显降低至 75W 左右,因此在我们的案例中,105W 的最大功率限制只是一个幻影。也许这是我们笔记本电脑的绝缘问题?在这里,我们必须提醒大家,LaptopMedia 中几乎所有的评测产品都来自网上商店,而不是使用制造商提供的评测样品。微星 Stealth 16 AI Studio A1V 也不例外。风扇噪音较大(但并不碍事),但键盘尤其是 WASD 部分在游戏过程中不会变得炙热。回到积极的方面–1600p 无 PWM IPS 显示屏(Innolux N160GME-GTB (CMN162F))确实不错。它视角宽广,刷新率为 240Hz,像素响应时间为 7 毫秒,非常适合游戏。由于采用了我们的 “设计与游戏 “配置文件(平均 dE 0.7),该面板还拥有完整的 sRGB 和 98% 的 DCI-P3 覆盖率,以及超级准确的色彩。对于喜欢在闲暇时间玩游戏的内容创作者来说,这无疑是个好消息。该产品的可升级性很好,端口选择也与时俱进,配备了两个 Type-C 端口和一个 MicroSD 读卡器。按键式 RGB 键盘非常舒适,触摸板也同样顺滑。对于这样的硬件和高分辨率显示屏来说,7 小时左右的视频续航时间似乎还不错。遗憾的是,糟糕的内存散热破坏了整个乐趣。尽管如此,Stealth 16 AI Studio 凭借其色彩精确的显示屏、舒适的输入设备、现代化的硬件和良好的制造质量,还是能给未来的买家留下深刻印象。
Single Review, online available, Very Long, Date: 08/01/2024

Foreign Reviews

MSI Stealth 16 AI Studio A1V review – Great Performance Held Back by Terrifying Overheating
Source: Laptop Media English EN→zh-CN
Thin and solid metal chassis that houses powerful hardware – this describes best the MSI Stealth 16 AI Studio A1V. The cooling with its five heat pipes and a pair of fans is potent. That’s why the Intel Core Ultra 9 185H can boost its P and E cores to around 3.20 GHz / 2.70 GHz in long loads and yes, that is a good result for a thin laptop like this one. On the other hand, the high GPU memory temperatures cause notable TGP throttling to around 75W in “Extreme Performance” mode so in our case the max power limit of 105W is just a mirage. Maybe this is an insulated issue with our laptop? Here we have to remind you that almost all of the reviewed products in LaptopMedia come from online stores, instead of using review samples provided by the manufacturers. MSI Stealth 16 AI Studio A1V is not an exception.
Single Review, online available, Very Long, Date: 08/01/2024
How to open MSI Stealth 16 AI Studio A1V - disassembly and upgrade options
Source: Laptop Media English
Support, online available, Short, Date: 08/01/2024
Laptop MSI tích hợp AI – Thiết kế đẳng cấp và trí tuệ nhân tạo trên MSI Stealth 16 AI Studio
Source: FPT shop VN→zh-CN
Single Review, online available, Short, Date: 08/20/2024

Comment

NVIDIA NVIDIA GeForce RTX 4070 Laptop GPU:

基于 Ada Lovelace 架构的笔记本电脑高端显卡。提供 8 GB GDDR6(128 位),可配置为 35 - 115W(+ 动态升压)的 TGP。



» Further information can be found in our Comparison of Mobile Graphics Cards and the corresponding Benchmark List.


Ultra 9 185H: 2023 年 12 月亮相的顶级流星湖芯片。这款第 1 代酷睿 Ultra 处理器将取代第 13 代酷睿芯片;它拥有 16 个内核(6 + 8 + 2)和 22 个线程。其中,性能内核有 6 个,运行频率最高可达 5.1 GHz,而高效内核有 10 个(8 个主内核加上低功耗岛中的 2 个额外内核),运行频率最高可达 3.8 GHz。刚刚出炉的 8 核 Arc GPU 可用作集成图形适配器,其运行频率高达 2.35 GHz,此外还提供了大量其他全新技术,如集成的 AI Boost NPU(带有两个用于硬件 AI 工作负载加速的第 3 代引擎)。这款笔记本处理器的 "基本 "功耗为 45 W,而 Turbo 功耗不会超过 115 W。» Further information can be found in our Comparison of Mobile Processsors.


16.00": 15到16寸是笔记本电脑的标准尺寸,产品型号最为丰富。» To find out how fine a display is, see our DPI List.


1.99 kg: 大部分12到16寸的亚笔记本电脑,超极本和轻盈标准笔记本电脑的重量在这个水平上。


» Further information can be found in our Notebook Purchase Guide.
