MediaTek Dimensity 8020

Mediatek Dimensity 8020

联发科技 Dimensity 8020 是一款基于 ARM 的片上系统 (SoC)，类似于较早的 Dimensity 1100.它专门设计用于Android 智能手机，在性能方面属于中端产品。它支持当前所有的移动网络标准，包括采用 2CC-CA (200MHz) 和 FDD+TDD 的 5G。

中央处理器共有八个内核，分为两个集群。一个集群有四个 ARM Cortex-A78 性能内核，主频高达 2.6 GHz，另一个集群有四个 ARM Cortex-A55 节能内核，主频高达 2.0 GHz。内存采用 LPDDR4 RAM，内部存储支持 UFS 3.1。

在连接方面，它支持双 5G，以及 Wi-Fi 6 和蓝牙 5.2。

集成图形处理器、 ARM Mali-G77 MC9可支持分辨率高达 2560 x 1080、刷新率高达 144 Hz（可能仅适用于全高清+）的显示器。

该芯片由台积电（TSMC）采用当前中端市场的 6 纳米工艺制造。

CodenameCortex-A78 / A55
Clock Rate2000 - 2600 MHz
Number of Cores / Threads8 / 8
4 x 2.6 GHz ARM Cortex-A77
4 x 2.0 GHz ARM Cortex-A55
Manufacturing Technology6 nm
Features4x ARM Cortex-A77 (2.6 GHz), 4x ARM Cortex-A55 (2 GHz), ARM Mali-G77 MP9, APU 570, 5G Modem, MiraVision HDR10+, Wi-Fi 6, Bluetooth 5.2, UFS 3.1, LPDDR4x
GPUARM Mali-G77 MP9
64 Bit64 Bit support
ArchitectureARM
Announcement Date03/01/2022
Product Link (external)www.mediatek.com

Benchmarks

3DMark - 3DMark Sling Shot Extreme (ES 3.1) Unlimited Physics
5415 Points (51%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Sling Shot (ES 3.0) Unlimited Physics
3388 Points (39%)
+ 1 benchmarks and specifications   + Show comparison chart
Geekbench 6.3 - Geekbench 6.3 Single-Core
1120 points (29%)
+ 1 benchmarks and specifications   + Show comparison chart
Geekbench 6.3 - Geekbench 6.3 Multi-Core
3617 points (14%)
+ 1 benchmarks and specifications   - Hide comparison chart
Geekbench 5.5 - Geekbench 5.1 - 5.5 64 Bit Single-Core
835 points (33%)
+ 1 benchmarks and specifications   - Hide comparison chart
Mediatek MT6737
58 -93%
...
MediaTek Dimensity 7050
791 -5%
Qualcomm Snapdragon 7 Gen 1
793 -5%
MediaTek Dimensity 1000+
796 -5%
MediaTek Dimensity 7300
808 -3%
Qualcomm Snapdragon 780G 5G
809 -3%
Qualcomm Snapdragon 778G+ 5G
821 -2%
Samsung Exynos 9820
825 -1%
MediaTek Dimensity 1200
833 0%
Samsung Exynos 9825
834 0%
MediaTek Dimensity 8020
835
Apple A10X Fusion
850 2%
MediaTek Dimensity 8050
868 4%
Qualcomm QCM6490
870 4%
Qualcomm Snapdragon 7 Gen 3
874 5%
Qualcomm Snapdragon 7+ Gen 3
876 5%
MediaTek Dimensity 7350 Pro 5G
889 6%
MediaTek Dimensity 7200
889 6%
Samsung Exynos 1480
891 7%
Qualcomm Snapdragon 865
903 8%
...
Apple A18 Pro
2437 192%
max:
Apple M4 Pro (12 cores)
2555 206%
0%
100%
Geekbench 5.5 - Geekbench 5.1 - 5.5 64 Bit Multi-Core
3310 points (6%)
+ 1 benchmarks and specifications   - Hide comparison chart
Mediatek MT6580M
248 -93%
...
Qualcomm Snapdragon 780G 5G
2998 -9%
Qualcomm Snapdragon 778G 4G
3020 -9%
HiSilicon Kirin 990 5G
3077 -7%
Google Tensor G2
3198 -3%
Qualcomm Snapdragon 888 4G
3207 -3%
Qualcomm Snapdragon 865+ (Plus)
3243 -2%
Qualcomm Snapdragon 870 5G
3245 -2%
Qualcomm Snapdragon 7 Gen 3
3257 -2%
Qualcomm Snapdragon 865
3268 -1%
MediaTek Dimensity 8020
3310
Samsung Exynos 1480
3349 1%
Apple A13 Bionic
3381 2%
Samsung Exynos 2100 5G
3392 2%
Google Tensor G3
3462 5%
Qualcomm Snapdragon 8 Gen 1
3548 7%
Qualcomm Snapdragon G3x Gen 1
3553 7%
Qualcomm Snapdragon 888 5G
3571 8%
Qualcomm Snapdragon 888 Plus 5G
3572 8%
Samsung Exynos 2200
3600 9%
...
Apple M3
10697 223%
max:
AMD Ryzen Threadripper PRO 7995WX
55811 1586%
0%
100%
Geekbench 5.0 - Geekbench 5.0 64 Bit Single-Core
836 points (4%)
+ 1 benchmarks and specifications   + Show comparison chart
Geekbench 5.0 - Geekbench 5.0 64 Bit Multi-Core
3280 points (10%)
+ 1 benchmarks and specifications   + Show comparison chart
Geekbench 4.4 - Geekbench 4.1 - 4.4 64 Bit Single-Core
3906 points (39%)
+ 1 benchmarks and specifications   + Show comparison chart
Geekbench 4.4 - Geekbench 4.1 - 4.4 64 Bit Multi-Core
12596 points (13%)
+ 1 benchmarks and specifications   + Show comparison chart
Geekbench 4.0 - Geekbench 4.0 64 Bit Single-Core
3785 points (52%)
+ 1 benchmarks and specifications   + Show comparison chart
Geekbench 4.0 - Geekbench 4.0 64 Bit Multi-Core
12041 points (29%)
+ 1 benchmarks and specifications   + Show comparison chart
Geekbench 3 - Geekbench 3 64 Bit Multi-Core
15079 points (24%)
+ 1 benchmarks and specifications   + Show comparison chart
Geekbench 3 - Geekbench 3 64 Bit Single-Core
4298 points (64%)
+ 1 benchmarks and specifications   + Show comparison chart
Mozilla Kraken 1.1 - Kraken 1.1 Total Score *
1739 ms (2%)
+ 1 benchmarks and specifications   + Show comparison chart
Octane V2 - Octane V2 Total Score
28282 Points (24%)
+ 1 benchmarks and specifications   + Show comparison chart
WebXPRT 4 - WebXPRT 4 Score
78 Points (22%)
+ 1 benchmarks and specifications   + Show comparison chart
WebXPRT 3 - WebXPRT 3 Score
87 Points (16%)
+ 1 benchmarks and specifications   + Show comparison chart
Antutu v9 - AnTuTu v9 Total Score
687619 Points (33%)
+ 1 benchmarks and specifications   + Show comparison chart
Antutu v9 - AnTuTu v9 CPU
172354 Points (43%)
+ 1 benchmarks and specifications   + Show comparison chart
PCMark for Android - PCM f. Android Storage 2.0 score
31713 Points (14%)
+ 1 benchmarks and specifications   + Show comparison chart
PCMark for Android - PCM f. Android Work Score 3.0
16611 Points (61%)
+ 1 benchmarks and specifications   + Show comparison chart
CrossMark - CrossMark Overall
620 Points (24%)
+ 1 benchmarks and specifications   + Show comparison chart
Power Consumption - Geekbench 5.5 Power Consumption 150cd *
4.5 Watt (2%)
+ 1 benchmarks and specifications   + Show comparison chart
01234567891011Tooltip
Power Consumption - Idle Power Consumption 150cd 1min *
1.1 Watt (1%)
+ 1 benchmarks and specifications   + Show comparison chart
00.10.10.20.20.30.30.40.50.50.60.60.70.80.80.90.9111.1Tooltip
- Range of benchmark values for this graphics card
red legend - Average benchmark values for this graphics card
* Smaller numbers mean a higher performance
