NVIDIA GeForce GT 520M

NVIDIA GeForce GT 520M

NVIDIA GeForce GT 520M是一款入门级的专用笔记本电脑的图形卡在2010年提出。它是基于GF119或GF108核心，这两者都是有关Fermi架构。根据不同的版本，它采用了64位内存总线和更高的时钟频率（GF119版本）或128位内存总线和较慢的时钟速率。从理论上讲，该卡还支持快速的GDDR5内存，但由于成本的限制，DDR3将使用的笔记本电脑制造商。相比GT 420M，520M仅提供了48，而不是96个着色器核心。 GF108 - 核心600/1200兆赫，128位900 MHz的DDR3GF119的 - 核心一千四百八十〇分之七百四兆赫，64位800 MHz的DDR3架构GF1​​19拥有48个ALU，8个纹理单元和64位内存接口，为DDR3 VRAM。因此，它类似于一个半GF108（GeForce®（精视™）GT 540M），但已经与优化晶体管制造。光栅操作处理器（ROP）的差异保持同样的计算4。的GF119是smalles的芯片的费米生成用于低端笔记本电脑。作为一款入门级的卡片的性能，GT 520M在目前的Sandy Bridge处理器一争高下的英特尔HD Graphics 3000。在我们的测试中，该卡只稍快一些，但做更好的驱动程序支持的差异。然而，无法播放等要求苛刻的游戏战地3“巫师2。其他现代游戏只能运行在低细节，因此玩家不会很高兴的表现。低要求苛刻的游戏，如FIFA 12，然而，高细节设定播放。至于其他的500M系列芯片的特点，520M支持通过HDMI输出码流高清音频（蓝光）。这意味着该卡能够转移到高保真接收器Dolby True HD和DTS-HD比特流明智的，没有质量损失。的GT520M提供的PureVideo HD视频解码技术。视频处理器（VP4）在GF108芯片支持的特征集C的GPU，因此能够完全解码MPEG-1，MPEG-2，MPEG-4第2部分（MPEG-4 ASP - 例如，DivX或XviD） ，VC-1/WMV9，H.264（VLD，IDCT，运动补偿，去块“）。较新的GF119已经支持下一代VP5（功能集D）与更快的解码，HD-SD转码，低功耗解码和4K x 4K分辨率的H.264解码支持。此外，GPU能够解码两个1080p视频流，同时（如蓝光图片，图片）。通过CUDA，OpenCL的，和DirectCompute 2.1的支持，GeForce GT 520M的可以帮助一般计算的。例如，流处理器能显着更快编码视频不是一个快速的CPU。此外，可以从理论上做物理计算的GPU PhysX物理（如黑手党2“地铁2033”），但性能不会，这是足够的。的功耗约为17瓦（包括主板和内存）允许使用小型笔记本电脑的520M。此外，Optimus是支持（如果实现由制造商）自动切换到处理器的图形卡，以节省电力。

GeForce GT 500M Series

GeForce GT 555M 144 @ 0.53 - 0.75 GHz128, 192 Bit @ 785-900 MHz
GeForce GT 550M 96 @ 0.74 GHz128 Bit @ 900 MHz
GeForce GT 540M 96 @ 0.67 GHz128 Bit @ 900 MHz
GeForce GT 525M 96 @ 0.6 GHz128 Bit @ 900 MHz
GeForce GT 520MX 48 @ 0.9 GHz64 Bit @ 900 MHz
GeForce GT 520M 48 @ 0.74 GHz64 / 128 Bit @ 800 / 900 MHz
CodenameN12P-GP/LV
ArchitectureFermi
Pipelines48 - unified
Core Speed740 / 600 MHz
Shader Speed1480 / 1200 MHz
Memory Speed800 / 900 MHz
Memory Bus Width64 / 128 Bit
Memory TypeDDR3 (GDDR5)
Max. Amount of Memory1536 MB
Shared Memoryno
APIDirectX 11, Shader 5.0
Power Consumption17 Watt
technology40 nm
FeaturesPhysX, Verde Drivers, CUDA, Optimus, DirectCompute, OpenCL, DirectX11, OpenGL 4.1
Date of Announcement05.01.2011

Benchmarks

3DMark 11 - 3DM11 Performance Score
min: 510     avg: 565     median: 568.5 (1%)     max: 632 Points
+ 12 benchmarks and specifications   + Show comparison chart
3DMark 11 - 3DM11 Performance GPU
min: 451     avg: 499.8     median: 502 (0%)     max: 557 Points
+ 12 benchmarks and specifications   - Hide comparison chart
AMD Radeon HD 6250
171.8 -66%
...
AMD Radeon HD 6450M
443 -11%
AMD Radeon HD 7420G
453 -9%
AMD Radeon HD 6480G
467 -7%
Intel HD Graphics 405 (Braswell)
469.1 -6%
AMD Radeon R2 (Mullins/Beema/Carrizo-L)
471.7 -6%
Intel HD Graphics 500
478.6 -4%
Intel HD Graphics (Haswell)
479.6 -4%
AMD Radeon HD 6520G
492 -2%
AMD Radeon HD 8280
496 -1%
NVIDIA GeForce GT 520M
499.8
NVIDIA GeForce 610M
513 3%
NVIDIA NVS 4200M
519 4%
AMD Radeon HD 7470M
522 4%
Intel HD Graphics 4000
522 4%
AMD Radeon HD 6470M
531 6%
AMD Radeon HD 8330
532 6%
Intel UHD Graphics 600
558 12%
AMD Radeon R3 (Mullins/Beema)
576 15%
AMD Radeon HD 7450M
582 16%
...
AMD Radeon RX 7900M
59943 11893%
max:
NVIDIA GeForce RTX 4090
104201 20749%
0%
100%
3DMark Vantage
3DM Vant. Perf. total +
3DMark Vantage - 3DM Vant. Perf. total
min: 1513     avg: 2218     median: 2280 (1%)     max: 2357 Points
+ 11 benchmarks and specifications   + Show comparison chart
3DM Vant. Perf. GPU no PhysX +
3DMark Vantage - 3DM Vant. Perf. GPU no PhysX
min: 1188     avg: 1769     median: 1825 (1%)     max: 1898 Points
+ 11 benchmarks and specifications   - Hide comparison chart
ATI Radeon HD 3200
62 -96%
...
AMD Radeon HD 7470M
1516 -14%
NVIDIA GeForce 9700M GT
1535 -13%
AMD Radeon HD 6620G
1535 -13%
NVIDIA GeForce 320M
1543 -13%
AMD Radeon HD 8400
1655 -6%
NVIDIA GeForce 8600M GT SLI
1665 -6%
NVIDIA GeForce 8700M GT
1694 -4%
Intel HD Graphics 405 (Braswell)
1730 -2%
NVIDIA GeForce GT 325M
1753 -1%
NVIDIA GeForce GT 520M
1769
NVIDIA GeForce 8700M GT SLI
1783 1%
Intel UHD Graphics 605
1785 1%
ATI Mobility Radeon HD 550v
1804 2%
AMD Radeon R4 (Kaveri)
1811 2%
AMD Radeon HD 8610G
1817 3%
Intel UHD Graphics 600
1836 4%
AMD Radeon HD 8450G
1853 5%
Intel HD Graphics (Haswell)
1859 5%
NVIDIA GeForce 610M
1880 6%
...
NVIDIA GeForce RTX 4090 Laptop GPU
132443 7387%
max:
AMD Radeon RX 7900 XTX
170928 9562%
0%
100%
3DMark 2001SE - 3DMark 2001 - Standard
min: 11778     avg: 19118     median: 20926 (22%)     max: 24651 Points
+ 3 benchmarks and specifications   + Show comparison chart
3DMark 03 - 3DMark 03 - Standard
min: 11351     avg: 12201     median: 12227 (6%)     max: 13147 Points
+ 5 benchmarks and specifications   + Show comparison chart
3DMark 05 - 3DMark 05 - Standard
min: 8461     avg: 9070     median: 9098 (10%)     max: 9337 Points
+ 7 benchmarks and specifications   - Hide comparison chart
Intel Graphics Media Accelerator (GMA) 500
133.4 -99%
...
Intel HD Graphics 4400
8674 -4%
NVIDIA GeForce GT 220M
8696 -4%
AMD Radeon HD 7550M
8746 -4%
ATI Mobility Radeon HD 2600 XT
8769 -3%
AMD Radeon HD 6755G2
8810 -3%
ATI Mobility Radeon HD 3850
8816 -3%
NVIDIA GeForce 9600M GS
8844 -2%
AMD Radeon R4 (Stoney Ridge)
8856 -2%
Intel UHD Graphics Xe 750 32EUs (Rocket Lake)
8935 -1%
NVIDIA GeForce GT 520M
9070
NVIDIA Quadro NVS 320M
9075 0%
NVIDIA GeForce 8700M GT
9102 0%
Intel HD Graphics 515
9173 1%
NVIDIA GeForce 9650M GS
9212 2%
NVIDIA Quadro FX 3500M
9295 2%
NVIDIA GeForce GT 120M
9472 4%
AMD Radeon HD 7520G
9477 4%
NVIDIA NVS 4200M
9507 5%
AMD Radeon HD 6490M
9512 5%
...
AMD Radeon RX 7600M XT
69623 668%
max:
NVIDIA GeForce RTX 4080 Super
87172 861%
0%
100%
3DMark 06 3DMark 06 - Score Unknown Settings +
3DMark 06
min: 5284     avg: 5476     median: 5476 (7%)     max: 5668 points
+ 2 benchmarks and specifications   + Show comparison chart
3DMark 06 - Standard 1280x1024 +
3DMark 06
min: 4432     avg: 4762     median: 4742.5 (6%)     max: 5353 Points
+ 8 benchmarks and specifications   + Show comparison chart
3DMark 06 - Standard 1280x768 +
3DMark 06
min: 4980     avg: 5133     median: 5100 (7%)     max: 5318 Points
+ 3 benchmarks and specifications   + Show comparison chart
Unigine Heaven 2.1 - Heaven 2.1 high
min: 6.9     avg: 7.6     median: 7.7 (1%)     max: 8 fps
+ 6 benchmarks and specifications   - Hide comparison chart
AMD Radeon HD 7310
0.6 -92%
...
Intel HD Graphics (Sandy Bridge)
5.7 -25%
Intel HD Graphics (Cherry Trail)
5.7 -25%
AMD Radeon HD 6470M
6.2 -19%
AMD Radeon HD 6490M
6.7 -12%
AMD Radeon HD 7450M
6.85 -10%
AMD Radeon HD 7520G
6.85 -10%
NVIDIA GeForce 310M
7 -8%
Intel HD Graphics 405 (Braswell)
7.4 -3%
NVIDIA NVS 4200M
7.45 -2%
NVIDIA GeForce GT 520M
7.617
NVIDIA GeForce 610M
7.675 1%
Intel HD Graphics 3000
7.7 1%
AMD Radeon R2 (Stoney Ridge)
7.8 2%
AMD Radeon HD 7550M
8.1 6%
AMD Radeon R4 (Stoney Ridge)
8.35 10%
ATI Mobility Radeon HD 545v
8.7 14%
AMD Radeon HD 6520G + HD 7450M Dual Graphics
8.867 16%
Intel HD Graphics 505
8.9 17%
Intel UHD Graphics 605
9 18%
...
NVIDIA Quadro RTX 5000 (Laptop)
532 6884%
0%
100%
SPECviewperf 11
specvp11 snx-01 +
SPECviewperf 11 - specvp11 snx-01
min: 2.34     avg: 2.4     median: 2.4 (1%)     max: 2.52 fps
+ 2 benchmarks and specifications   + Show comparison chart
specvp11 tcvis-02 +
SPECviewperf 11 - specvp11 tcvis-02
min: 0.7     avg: 0.7     median: 0.7 (0%)     max: 0.73 fps
+ 2 benchmarks and specifications   + Show comparison chart
specvp11 sw-02 +
SPECviewperf 11 - specvp11 sw-02
5.1 fps (4%)
+ 2 benchmarks and specifications   + Show comparison chart
specvp11 proe-05 +
SPECviewperf 11 - specvp11 proe-05
min: 0.79     avg: 0.8     median: 0.8 (1%)     max: 0.8 fps
+ 2 benchmarks and specifications   + Show comparison chart
specvp11 maya-03 +
SPECviewperf 11 - specvp11 maya-03
min: 5.41     avg: 5.5     median: 5.5 (4%)     max: 5.53 fps
+ 2 benchmarks and specifications   + Show comparison chart
specvp11 lightwave-01 +
SPECviewperf 11 - specvp11 lightwave-01
min: 6.93     avg: 7.2     median: 7.2 (8%)     max: 7.4 fps
+ 2 benchmarks and specifications   + Show comparison chart
specvp11 ensight-04 +
SPECviewperf 11 - specvp11 ensight-04
min: 5.29     avg: 5.6     median: 5.6 (3%)     max: 5.82 fps
+ 2 benchmarks and specifications   + Show comparison chart
specvp11 catia-03 +
SPECviewperf 11 - specvp11 catia-03
min: 2.46     avg: 2.5     median: 2.5 (1%)     max: 2.55 fps
+ 2 benchmarks and specifications   + Show comparison chart
Windows 7 Experience Index - Win7 Gaming graphics
min: 6.4     avg: 6.4     median: 6.4 (81%)     max: 6.5 Points
+ 9 benchmarks and specifications   + Show comparison chart
Windows 7 Experience Index - Win7 Graphics
min: 4.6     avg: 5     median: 4.7 (59%)     max: 5.8 Points
+ 9 benchmarks and specifications   + Show comparison chart
Cinebench R10 Cinebench R10 Shading (32bit) +
Cinebench R10 - Cinebench R10 Shading (32bit)
min: 4234     avg: 4982     median: 4960 (4%)     max: 5794 points
+ 12 benchmarks and specifications   + Show comparison chart
Cinebench R11.5 Cinebench R11.5 OpenGL 64 Bit +
Cinebench R11.5 - Cinebench R11.5 OpenGL 64 Bit
min: 13     avg: 15     median: 15.5 (5%)     max: 15.5 fps
+ 12 benchmarks and specifications   + Show comparison chart
- Range of benchmark values for this graphics card
red legend - Average benchmark values for this graphics card
* Smaller numbers mean a higher performance

Game Benchmarks

The following benchmarks stem from our benchmarks of review laptops. The performance depends on the used graphics memory, clock rate, processor, system settings, drivers, and operating systems. So the results don't have to be representative for all laptops with this GPU. For detailed information on the benchmark results, click on the fps number.

Anno 2070

Anno 2070

2011
low 1024x768
44.4 47.5 ~ 46 fps    + Compare
med. 1366x768
17.2 17.7 ~ 17 fps    + Compare
high 1366x768
10.8 10.9 ~ 11 fps    + Compare
» With all tested laptops playable in detail settings low.
The Elder Scrolls V: Skyrim

The Elder Scrolls V: Skyrim

2011
low 1280x720
25.1 27.6 ~ 26 fps    + Compare
med. 1366x768
17.2 18 ~ 18 fps    + Compare
high 1366x768
11.4 11.5 ~ 11 fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Battlefield 3

Battlefield 3

2011
low 1024x768
20 21 ~ 21 fps    + Compare
med. 1366x768
11.5 14 ~ 13 fps    + Compare
high 1366x768
8.6 11 ~ 10 fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Fifa 12

Fifa 12

2011
low 800x600
196.2  fps    + Compare
med. 1024x768
95 95.4 ~ 95 fps    + Compare
high 1360x768
23 63 64.9 ~ 50 fps    + Compare
ultra 1920x1080
40  fps    + Compare
» With all tested laptops playable in detail settings ultra.
F1 2011

F1 2011

2011
low 800x600
66 69 ~ 68 fps    + Compare
med. 1024x768
36 43 ~ 40 fps    + Compare
high 1366x768
23 24 ~ 24 fps    + Compare
ultra 1920x1080
12  fps    + Compare
» With all tested laptops playable in detail settings med..
Deus Ex Human Revolution

Deus Ex Human Revolution

2011
low 1024x768
55 57.8 60 ~ 58 fps    + Compare
high 1366x768
21 22 22.1 26.8 ~ 23 fps    + Compare
ultra 1920x1080
7  fps    + Compare
» With all tested laptops playable in detail settings low.
Dirt 3

Dirt 3

2011
low 800x600
45.2 67.7 91.5 94.9 ~ 75 fps    + Compare
med. 1024x768
29.5 35.6 35.8 42.4 ~ 36 fps    + Compare
high 1360x768
18.6 23 23.1 31.1 ~ 24 fps    + Compare
ultra 1920x1080
12.6 12.6 ~ 13 fps    + Compare
» With most tested laptops playable in detail settings med..
The Witcher 2: Assassins of Kings

The Witcher 2: Assassins of Kings

2011
low 1024x768
15  fps    + Compare
med. 1366x768
9  fps    + Compare
high 1600x900
6  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Crysis 2

Crysis 2

2011
low 800x600
30.9 33 ~ 32 fps    + Compare
med. 1024x768
20.3 21 ~ 21 fps    + Compare
high 1366x768
16 16.2 ~ 16 fps    + Compare
ultra 1920x1080
5 5.4 ~ 5 fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Total War: Shogun 2

Total War: Shogun 2

2011
low 1024x768
62.4 77.5 ~ 70 fps    + Compare
med. 1280x720
6.4 6.4 ~ 6 fps    + Compare
ultra 1920x1080
3.9 3.9 ~ 4 fps    + Compare
» With all tested laptops playable in detail settings low.
Call of Duty: Black Ops

Call of Duty: Black Ops

2010
low 800x600
64  fps    + Compare
med. 1024x768
38  fps    + Compare
high 1360x768
30  fps    + Compare
ultra 1920x1080
16.8  fps    + Compare
» With all tested laptops playable in detail settings med..
Fifa 11

Fifa 11

2010
low 800x600
162 232 240.9 250.2 252.2 ~ 227 fps    + Compare
med. 1024x768
84.8 96 96.5 103.4 123.4 ~ 101 fps    + Compare
high 1360x768
64.3 68.8 72 76.4 79.9 ~ 72 fps    + Compare
ultra 1920x1080
40.4  fps    + Compare
» With all tested laptops playable in detail settings ultra.
Civilization 5

Civilization 5

2010
low 1024x768
20.3  fps    + Compare
ultra 1920x1080
5.7  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Mafia 2

Mafia 2

2010
low 800x600
28.4 34 36.4 36.4 37.4 37.7 ~ 35 fps    + Compare
med. 1024x768
21.5 24 24 26 27.4 27.6 ~ 25 fps    + Compare
high 1360x768
18.5 19 20.5 22 23 23.2 ~ 21 fps    + Compare
ultra 1920x1080
13 13.6 13.9 ~ 14 fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
StarCraft 2

StarCraft 2

2010
low 1024x768
113 137 137.2 144 149 150 ~ 138 fps    + Compare
med. 1360x768
24 25 26.8 27 28.8 32 ~ 27 fps    + Compare
high 1360x768
19 19 19 19 19.6 20.4 ~ 19 fps    + Compare
ultra 1920x1080
10 10 10.3 ~ 10 fps    + Compare
» With all tested laptops playable in detail settings low.
Just Cause 2

Just Cause 2

2010
ultra 1920x1080
6.1  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Metro 2033

Metro 2033

2010
low 800x600
31.1  fps    + Compare
med. 1360x768
17.1  fps    + Compare
high 1600x900
8.8  fps    + Compare
ultra 1920x1080
3.6  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Dawn of War II - Chaos Rising

Dawn of War II - Chaos Rising

2010
low 1024x768
64  fps    + Compare
med. 1366x768
31  fps    + Compare
high 1366x768
21.6  fps    + Compare
ultra 1920x1080
8.9  fps    + Compare
» With all tested laptops playable in detail settings low.
Battlefield: Bad Company 2

Battlefield: Bad Company 2

2010
low 1024x768
30 34 34 ~ 33 fps    + Compare
med. 1366x768
22 25 25.7 ~ 24 fps    + Compare
high 1366x768
16 18 18.3 ~ 17 fps    + Compare
ultra 1920x1080
8 8.9 ~ 8 fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Stalker: Call of Pripyat

Stalker: Call of Pripyat

2010
ultra 1920x1200
6.8  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
CoD Modern Warfare 2

CoD Modern Warfare 2

2009
low 800x600
65.1  fps    + Compare
med. 1024x768
34.1  fps    + Compare
high 1366x768
22.8  fps    + Compare
ultra 1920x1080
14.4  fps    + Compare
» With all tested laptops playable in detail settings low.
Risen

Risen

2009
low 800x600
43.1 49.9 53.8 54 ~ 50 fps    + Compare
med. 1024x768
16.4 19 19.8 23 ~ 20 fps    + Compare
high 1366x768
9.5 12.8 14.3 14.9 ~ 13 fps    + Compare
ultra 1920x1080
8.4  fps    + Compare
» With all tested laptops playable in detail settings low.
Resident Evil 5

Resident Evil 5

2009
low 800x600
89.2  fps    + Compare
high 1360x768
28.1  fps    + Compare
ultra 1920x1080
15.8  fps    + Compare
» With all tested laptops playable in detail settings low.
Need for Speed Shift

Need for Speed Shift

2009
low 800x600
37.4  fps    + Compare
med. 1024x768
22.1 24.4 25.1 26 ~ 24 fps    + Compare
high 1366x768
16.6 17.4 20.6 21.5 ~ 19 fps    + Compare
ultra 1920x1080
17.6  fps    + Compare
» With all tested laptops playable in detail settings low.
Colin McRae: DIRT 2

Colin McRae: DIRT 2

2009
low 800x600
39.4 40.5 65.4 65.6 ~ 53 fps    + Compare
med. 1024x768
34 36.9 43.7 44.8 ~ 40 fps    + Compare
high 1360x768
18.9 19.1 21.2 22.7 ~ 20 fps    + Compare
ultra 1920x1080
12.7  fps    + Compare
» With most tested laptops playable in detail settings med..
Anno 1404

Anno 1404

2009
low 1024x768
98  fps    + Compare
ultra 1280x1024
14  fps    + Compare
» With all tested laptops playable in detail settings low.
Sims 3

Sims 3

2009
med. 1024x768
53  fps    + Compare
high 1280x1024
26  fps    + Compare
» With all tested laptops playable in detail settings med..
F.E.A.R. 2

F.E.A.R. 2

2009
low 800x600
110.5  fps    + Compare
med. 1024x768
44.6  fps    + Compare
high 1280x1024
28.7  fps    + Compare
ultra 1920x1080
14.4  fps    + Compare
» With all tested laptops playable in detail settings med..
GTA IV - Grand Theft Auto

GTA IV - Grand Theft Auto

2008
low 800x600
38.8 51.6 ~ 45 fps    + Compare
med. 1024x768
28.3 28.5 ~ 28 fps    + Compare
high 1280x1024
19.6 19.8 ~ 20 fps    + Compare
» With all tested laptops playable in detail settings low.
Left 4 Dead

Left 4 Dead

2008
low 640x480
119  fps    + Compare
high 1024x768
46  fps    + Compare
» With all tested laptops playable in detail settings high.
Far Cry 2

Far Cry 2

2008
low 640x480
76.7  fps    + Compare
high 1024x768
32.2  fps    + Compare
ultra 1920x1080
11.8  fps    + Compare
» With all tested laptops playable in detail settings low.
Racedriver: GRID

Racedriver: GRID

2008
low 800x600
122  fps    + Compare
med. 1024x768
65.6  fps    + Compare
high 1280x1024
27.4  fps    + Compare
» With all tested laptops playable in detail settings med..
Trackmania Nations Forever

Trackmania Nations Forever

2008
low 640x480
239 245 ~ 242 fps    + Compare
high 1024x768
44 47.2 ~ 46 fps    + Compare
ultra 1920x1080
15 16.2 ~ 16 fps    + Compare
» With all tested laptops playable in detail settings high.
Call of Duty 4 - Modern Warfare

Call of Duty 4 - Modern Warfare

2007
low 800x600
48.8 133.5 142.2 ~ 108 fps    + Compare
med. 1024x768
34.9 57.2 60.5 ~ 51 fps    + Compare
» With most tested laptops playable in detail settings med..
Supreme Commander - FA Bench

Supreme Commander - FA Bench

2007
low 1024x768
47.2  fps    + Compare
med. 1024x768
30.7  fps    + Compare
high 1024x768
25.4  fps    + Compare
ultra 1920x1080
11.7  fps    + Compare
» With all tested laptops playable in detail settings low.
Crysis - GPU Benchmark

Crysis - GPU Benchmark

2007
low 1024x768
65 72.6 ~ 69 fps    + Compare
med. 1024x768
26 29.5 ~ 28 fps    + Compare
high 1024x768
16 16.7 ~ 16 fps    + Compare
ultra 1920x1080
3.9 4 ~ 4 fps    + Compare
» With all tested laptops playable in detail settings low.
Crysis - CPU Benchmark

Crysis - CPU Benchmark

2007
low 1024x768
59 64.4 ~ 62 fps    + Compare
med. 1024x768
25 28.9 ~ 27 fps    + Compare
high 1024x768
15 15.2 ~ 15 fps    + Compare
ultra 1920x1080
3.7 4 ~ 4 fps    + Compare
» With all tested laptops playable in detail settings low.
World in Conflict - Benchmark

World in Conflict - Benchmark

2007
low 800x600
148 154 ~ 151 fps    + Compare
med. 1024x768
41 43 ~ 42 fps    + Compare
high 1024x768
23 25 ~ 24 fps    + Compare
ultra 1920x1080
8 8 ~ 8 fps    + Compare
» With all tested laptops playable in detail settings med..
Call of Juarez Benchmark

Call of Juarez Benchmark

2006
high 1024x768
18 18.6 18.9 ~ 19 fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Half Life 2 - Lost Coast Benchmark

Half Life 2 - Lost Coast Benchmark

2005
high 1024x768
138 149.1 ~ 144 fps    + Compare
» With all tested laptops playable in detail settings high.
Quake 4

Quake 4

2005
ultra 1024x768
61  fps    + Compare
» With all tested laptops playable in detail settings ultra.
World of Warcraft

World of Warcraft

2005
low 800x600
196.5 199 ~ 198 fps    + Compare
med. 1024x768
67.9 69 ~ 68 fps    + Compare
high 1280x1024
19 28.6 ~ 24 fps    + Compare
» With all tested laptops playable in detail settings med..
Counter-Strike Source

Counter-Strike Source

2004
low 640x480
189  fps    + Compare
high 1024x768
134  fps    + Compare
» With all tested laptops playable in detail settings high.
Doom 3

Doom 3

2004
ultra 1024x768
98.6  fps    + Compare
» With all tested laptops playable in detail settings ultra.
Quake 3 Arena - Timedemo

Quake 3 Arena - Timedemo

1999
high 1024x768
181  fps    + Compare
» With all tested laptops playable in detail settings high.
lowmed.highultraQHD4K
Anno 2070461711
The Elder Scrolls V: Skyrim261811
Battlefield 3211310
Fifa 12196.2955040
F1 201168402412
Deus Ex Human Revolution58237
Dirt 375362413
The Witcher 2: Assassins of Kings1596
Crysis 23221165
Total War: Shogun 27064
Call of Duty: Black Ops64383016.8
Fifa 112271017240.4
Civilization 520.35.7
Mafia 235252114
StarCraft 2138271910
Just Cause 26.12
Metro 203331.117.18.83.6
Dawn of War II - Chaos Rising643121.68.9
Battlefield: Bad Company 23324178
Stalker: Call of Pripyat6.8
CoD Modern Warfare 265.134.122.814.4
Risen5020138.4
Resident Evil 589.228.115.8
Need for Speed Shift37.4241917.6
Colin McRae: DIRT 253402012.7
Anno 14049814
Sims 35326
F.E.A.R. 2110.544.628.714.4
GTA IV - Grand Theft Auto452820
Left 4 Dead11946
Far Cry 276.732.1711.8
Racedriver: GRID12265.627.4
Trackmania Nations Forever2424616
Call of Duty 4 - Modern Warfare10851
Supreme Commander - FA Bench47.230.725.411.7
Crysis - GPU Benchmark6928164
Crysis - CPU Benchmark6227154
World in Conflict - Benchmark15142248
Call of Juarez Benchmark19
Half Life 2 - Lost Coast Benchmark144
Quake 461
World of Warcraft1986824
Counter-Strike Source189134
Doom 398.6
Quake 3 Arena - Timedemo181
< 30 fps
< 60 fps
< 120 fps
≥ 120 fps		4
11
14
8		15
11
4
28
5
1
3		27
2
2






For more games that might be playable and a list of all games and graphics cards visit our Gaming List

v1.28
log 22. 02:09:20

#0 ran 0s before starting gpusingle class +0s ... 0s

#1 no ids found in url (should be separated by "_") +0s ... 0s

#2 not redirecting to Ajax server +0s ... 0s

#3 did not recreate cache, as it is less than 5 days old! Created at Thu, 19 Dec 2024 05:31:27 +0100 +0.001s ... 0.001s

#4 no comparison url found in template nbc.compare_page_1 needed +0.024s ... 0.025s

#5 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.025s

#6 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.025s

#7 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.026s

#8 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.026s

#9 composed specs +0s ... 0.026s

#10 did output specs +0s ... 0.026s

#11 start showIntegratedCPUs +0s ... 0.026s

#12 getting avg benchmarks for device 2072 +0.012s ... 0.038s

#13 got single benchmarks 2072 +0.062s ... 0.1s

#14 got avg benchmarks for devices +0s ... 0.1s

#15 min, max, avg, median took s +0.443s ... 0.543s

#16 before gaming benchmark output +0s ... 0.543s

#17 Got 277 rows for game benchmarks. +0.014s ... 0.557s

#18 composed SQL query for gamebenchmarks +0s ... 0.557s

#19 got data and put it in $dataArray +0.022s ... 0.578s

#20 benchmarks composed for output. +1.022s ... 1.6s

#21 no comparison url found in template nbc.compare_page_1 needed +0.003s ... 1.603s

#22 return log +0s ... 1.603s

No reviews found for this graphics card.

Please share our article, every link counts!
Mail Logo

» Comparison of GPUs
Detailed list of all laptop GPUs sorted by class and performance.

» Benchmark List
Sort and restrict laptop GPUs based on performance in synthetic benchmarks.

» Notebook Gaming List
Playable games for each graphics card and their average FPS results.

Class 1

Class 2

Radeon RX 6800S
GeForce RTX 5060 Laptop *
Radeon RX 7600M XT *
Radeon RX 7700S *
M3 Max 40-Core GPU *
M2 Max 38-Core GPU *
GeForce RTX 2080 Mobile
Radeon RX 6700M
M3 Max 30-Core GPU *
Quadro RTX 5000 (Laptop)
Radeon RX 7600M *
M4 32-core GPU *
M2 Max 30-Core GPU *
GeForce RTX 3060 Laptop GPU
M1 Max 32-Core GPU *
Radeon RX 7600S
GeForce RTX 2070 Super Mobile
GeForce RTX 2080 Super Max-Q
RTX A3000 Laptop GPU
M1 Max 24-Core GPU *
A770M *
Radeon RX 6650M XT *
M3 Pro 18-Core GPU *
M2 Pro 19-Core GPU *
Radeon RX 6650M
Radeon RX 6600M
Radeon RX 6700S
GeForce RTX 2070 Mobile
Quadro RTX 5000 Max-Q
GeForce RTX 2080 Max-Q
Radeon RX 5700M *
GeForce GTX 1080 Mobile
Quadro RTX 4000 (Laptop)
M3 Pro 14-Core GPU *
M2 Pro 16-Core GPU *
M1 Pro 16-Core GPU *
Radeon PRO W6600M *
GeForce RTX 2070 Super Max-Q
Quadro RTX 4000 Max-Q *
M1 Pro 14-Core GPU *
GeForce RTX 2070 Max-Q *
Radeon RX 6600S *
Quadro P5200
Quadro RTX 3000 (Laptop) *
GeForce RTX 5050 Laptop *
GeForce RTX 2060 Mobile
Quadro RTX 3000 Max-Q *
GeForce GTX 1080 Max-Q
GeForce GTX 1070 Mobile
GeForce RTX 2060 Max-Q *
Quadro P4200
NVIDIA GeForce RTX 4050 Laptop GPU
Nvidia RTX 1000 Ada Generation Laptop GPU
RTX A2000 Laptop GPU
A730M *
Radeon Pro 5600M *
Radeon RX 5600M
Quadro P5000
GeForce GTX 1660 Ti Mobile
GeForce RTX 3050 Ti Laptop GPU
GeForce RTX 3050 6GB Laptop GPU
A570M *
RTX A1000 Laptop GPU
GeForce GTX 1070 Max-Q
A550M *
Quadro P5000 Max-Q *
Radeon 890M *
GeForce RTX 3050 A Laptop GPU
GeForce RTX 3050 4GB Laptop GPU
Nvidia RTX 500 Ada Generation Laptop GPU
A530M *
GeForce GTX 1660 Ti Max-Q
RTX A500 Laptop GPU
Radeon RX 6550M *
Radeon RX 6500M
Radeon RX 6550S *
GeForce GTX 980 (Laptop)
Quadro M5500
Quadro P4000
Quadro T2000 (Laptop) *
GeForce GTX 1060 Mobile
GeForce GTX 1650 Ti Mobile
A370M *
Radeon RX 5500M
Radeon Pro 5500M *
Quadro P4000 Max-Q
Quadro P3200
Radeon RX 580X (Laptop) *
Radeon RX 580 (Laptop)
Radeon RX 6450M *
Arc 8-Core *
GeForce RTX 2050 Mobile
Arc 140V *
GeForce MX570 *
Radeon RX 6300M *
Arc 130V *
GeForce GTX 1650 Mobile
Radeon Pro 5300M
Radeon RX 5300M
Quadro P3000
GeForce GTX 1060 Max-Q
Quadro P3000 Max-Q *
GeForce GTX 1650 Ti Max-Q *
Quadro T2000 Max-Q *
Quadro T1000 (Laptop) *
Radeon Pro WX 7100 *
Arc 7-Core *
Radeon RX 570X (Laptop) *

Class 3

M4 8-Core GPU *
Radeon RX 570 (Laptop) *
Radeon RX 470 (Laptop) *
GeForce GTX 1650 Max-Q *
T1200 Laptop GPU *
Quadro T1000 Max-Q *
A310 *
A350M *
T600 Laptop GPU *
T550 Laptop GPU *
GeForce GTX 980M
Vega M GH
Quadro M5000M
Radeon Pro Vega 20
Radeon 880M *
Adreno 830 *
Adreno X1-85 4.6 TFLOPS *
Radeon 780M *
GeForce MX550
GeForce GTX 1050 Ti Mobile
Radeon 680M
Quadro P2000
Quadro P2000 Max-Q
Quadro M4000M
GeForce GTX 970M
T500 Laptop GPU *
GeForce MX450 *
Radeon R9 M395X
GeForce GTX 1050 Ti Max-Q *
Radeon Pro Vega 16
Vega M GL / 870
WX Vega M GL
Radeon R9 M485X
Quadro M3000M
GeForce GTX 1050 Mobile
FirePro W7170M
Radeon R9 M395
GeForce GTX 1050 Max-Q *
Radeon 760M *
Adreno X1-85 3.8 TFLOPS *
Radeon Radeon Steam Deck 8CU
Radeon 660M
Radeon Pro WX 4150 *
GeForce GTX 965M
Radeon RX 560X (Laptop)
Radeon RX 560 (Laptop)
Quadro M2200
Radeon RX 460 (Laptop)
Quadro P1000
Radeon R9 M390
Xe MAX
Radeon Pro 560X
Radeon Pro 560
Radeon Pro 460
Radeon Pro WX 4130 *
Iris Xe G7 96EUs
GeForce MX350
GeForce GTX 960M
Quadro M1200
Quadro P620 *
Radeon RX 550X (Laptop)
Radeon RX 550 (Laptop)
Radeon RX 640
Radeon Pro WX 3200 *
Radeon Pro 555X
Radeon Pro 555
Radeon Pro 455
Quadro P600
GeForce MX250
GeForce MX330
GeForce MX150
Iris Xe G7 80EUs
Graphics 4-Core *
Quadro M2000M
Radeon RX 540X *
Radeon Pro WX 2100 *
Radeon RX 540 *
Radeon Pro WX 3100 *
GeForce GTX 950M
Radeon Pro 450
Adreno X1-45 2.1 TFLOPS *
Radeon 630
Radeon 540X *
Radeon R9 M470X *
Radeon R9 M385X
Quadro P520
Quadro M1000M
Quadro M620 *
GeForce 945M
Quadro P500 *
UHD Graphics 64EUs
Iris Plus Graphics G7 (Ice Lake 64 EU) *
Vega 10 *
Iris Pro Graphics P580
Iris Pro Graphics 580
Adreno X1-45 1.7 TFLOPS *
Radeon R9 M470 *
FirePro W5170M *
Radeon R9 M370X
Vega 9
FirePro W5130M
UHD Graphics Xe G4 48EUs *
UHD Graphics 32EUs
UHD Graphics Xe 32EUs (Tiger Lake-H) *
UHD Graphics 750
Radeon 740M *
UHD Graphics 730
GeForce MX230
Vega 8 *
Vega 7
Radeon R7 M465
Iris Pro Graphics 6200
GeForce MX130
GeForce 940MX
Quadro M520
Vega 8
GeForce 940M
Iris Plus Graphics G4 (Ice Lake 48 EU)
GeForce 930MX
Quadro M600M
FirePro W4190M
Radeon R9 M375
Iris Plus Graphics 655
Radeon R7 M445
Quadro M500M
Iris Plus Graphics 650
GeForce 930M
Iris Graphics 550
Radeon 530
Radeon 625
Vega 6 *
Iris Plus Graphics 645
GeForce MX110 *
Iris Plus Graphics 640
GeForce 920MX
Iris Graphics 540
UHD Graphics 24EUs (Alder Lake-N) *
Radeon R7 (Bristol Ridge) *
Radeon R7 M460 *
Radeon R7 M360
GeForce 920M
Radeon R8 M445DX
Radeon 620
Radeon R7 M440
Radeon R7 M340
Radeon 520
Radeon 610
Radeon Graphics (Ryzen 7000)
Radeon 610M *
Vega 6 *
Vega 5 *
UHD Graphics G1 (Ice Lake 32 EU)
UHD Graphics Xe 16EUs (Tiger Lake-H) *
HD Graphics 530
Radeon R5 (Bristol Ridge)
UHD Graphics 620
HD Graphics 620
Adreno 690 *
Adreno 685 *
Adreno 680 *
Radeon R5 M330
Radeon R5 M430
Vega 3 *
GeForce 910M
HD Graphics 520
Iris Graphics 6100

Class 4

Radeon R5 M320 *
Radeon R5 M315 *
Radeon R5 M420 *
Vega 2 *
Radeon R5 (Stoney Ridge)
HD Graphics 6000
UHD Graphics (Jasper Lake 32 EU) *
UHD Graphics 617
UHD Graphics 615
UHD Graphics (Jasper Lake 24 EU) *
HD Graphics 615
HD Graphics 515
UHD Graphics 610
HD Graphics 610
HD Graphics 510
UHD Graphics (Jasper Lake 16 EU)
UHD Graphics 605
HD Graphics 505
Radeon R4 (Stoney Ridge)
Radeon R2 (Stoney Ridge)
VideoCore VII *
UHD Graphics 600
HD Graphics 500
HD Graphics 405 (Braswell)
HD Graphics (Braswell)
HD Graphics 400 (Braswell)
GeForce GT 520M

* Approximate position of the graphics adapter
