NVIDIA GeForce®（精视™）GTX 670MX是一个高端的DirectX 11.1兼容的图形卡的笔记本电脑。在不同的类似称为费米GTX 670M，670MX采用了28nm制GK106核心的的开普勒架构（675MX和680M）的基础上。相类似GTX 675MX，670MX 67,2比115,2 GB / s的由于减少的接口宽度192位和慢时钟频率的内存芯片，提供了一个更小的内存带宽。开普勒架构架构是继承Fermi架构的GeForce 400M系列笔记本电脑第一次出现在。 GK106开普勒核心提供五种着色器块，称为SMX，以相同的速度的时钟作为中央纤芯。在GTX 670MX，所有5个街区，是活跃的960个CUDA核心。虽然越来越多的着色器核心可在开普勒架构相比，Fermi设计，开普勒着色器仍有望高达两倍的电源效率。然而，由于缺少的热时钟着色器域，两个着色器的开普勒芯片是类似的速度的一个着色器的费米芯片（作为后者的时钟快两倍）。现在支持PCIe 3.0的移动开普勒系列和可选的Turbo模式可以自动超频Nvidia显卡的理论的15％，如果笔记本电脑的散热系统，使得它。升压模式的实施，这是在BIOS中完成的，但它最终依赖于制造商的笔记本电脑。性能的GeForce®（精视™）GTX 670MX显卡的性能应该是GTX 670M以上，因此2012年的移动显卡在高端类。只有在极其苛刻的标题巫师2可能无法运行流利的在超低设置。战地3，天际和孤岛危机2，例如，在最高的详细设置播放。现在采用改进的功能集，包括支持高达4个主动的显示器。此外，高达3840x2160像素的高分辨率显示器，可以连接使用DisplayPort 1.2和HDMI 1.4a规范，如果有的话。 ，如Dolby TrueHD和DTS-HD，HD音频编解码器，可以通过比特流模式下，通过HDMI端口传输。然而，由于大多数笔记本电脑将采用擎天柱，集成的图形处理器（GPU）将有可能在显示器端口直接控制，可能会限制该功能由Nvidia的开普勒卡的设置。第5代PureVideo HD视频处理器（VP5）也集成在GK104核心，并提供高清视频的硬件解码。常见的编解码器，如MPEG-1/2，MPEG-4 ASP，H.264和VC1/WMV9完全支持4K分辨率，而VC1和MPEG-4支持高达1080p。两个数据流可以并行解码的功能，如图片，在图片。另一个新的特点是包含一个专用的视频编码引擎，类似英特尔QuickSync的NVENC API可以访问。 GeForce®（精视™）GTX 670MX的功耗应该是相似的GTX 670M，因此最适合用于大笔记本电脑（17英寸或更大）和台式机替代品。
GeForce GTX 600M Series
| |||||||||||||||||||||||||||||||
| Codename | N13E-GR | ||||||||||||||||||||||||||||||
| Architecture | Kepler | ||||||||||||||||||||||||||||||
| Pipelines | 960 - unified | ||||||||||||||||||||||||||||||
| Core Speed | 600 MHz | ||||||||||||||||||||||||||||||
| Memory Speed | 2800 MHz | ||||||||||||||||||||||||||||||
| Memory Bus Width | 192 Bit | ||||||||||||||||||||||||||||||
| Memory Type | GDDR5 | ||||||||||||||||||||||||||||||
| Shared Memory | no | ||||||||||||||||||||||||||||||
| API | DirectX 11, Shader 5.1, OpenGL 4.2 | ||||||||||||||||||||||||||||||
| Power Consumption | 75 Watt | ||||||||||||||||||||||||||||||
| Transistor Count | 2.5 Billion | ||||||||||||||||||||||||||||||
| technology | 28 nm | ||||||||||||||||||||||||||||||
| Features | Optimus, SLI, PhysX, Verde Drivers, CUDA, 3D Vision, 3DTV Play | ||||||||||||||||||||||||||||||
| Notebook Size | large | ||||||||||||||||||||||||||||||
| Date of Announcement | 01.10.2012 | ||||||||||||||||||||||||||||||
| Link to Manufacturer Page | www.geforce.com | ||||||||||||||||||||||||||||||
- Average benchmark values for this graphics cardThe following benchmarks stem from our benchmarks of review laptops. The performance depends on the used graphics memory, clock rate, processor, system settings, drivers, and operating systems. So the results don't have to be representative for all laptops with this GPU. For detailed information on the benchmark results, click on the fps number.
| low | med. | high | ultra | QHD | 4K | |
|---|---|---|---|---|---|---|
| Titanfall | 60 | 57.8 | 48.1 | 35.3 | ||
| Thief | 54.6 | 39.7 | 34.4 | 18.5 | ||
| Assassin´s Creed IV: Black Flag | 61 | 50.2 | 31.8 | 16.3 | ||
| X-Plane 10.25 | 82.5 | 38.9 | 22.3 | 13.7 | ||
| Call of Duty: Ghosts | 81.1 | 65.5 | 38 | 19.2 | ||
| Battlefield 4 | 98.4 | 68.8 | 44.9 | 18.6 | ||
| Batman: Arkham Origins | 201 | 132 | 64 | 31 | ||
| F1 2013 | 154 | 120 | 111 | 61 | ||
| Fifa 14 | 450.4 | 316.9 | 315.9 | 238.6 | ||
| Total War: Rome II | 156.8 | 116.4 | 91.3 | 16.6 | ||
| Saints Row IV | 77 | 67.9 | 38.1 | 24.8 | ||
| The Bureau: XCOM Declassified | 119.6 | 84.4 | 33.8 | 17.4 | ||
| Splinter Cell: Blacklist | 93.3 | 82.8 | 38.8 | 17.9 | ||
| Dota 2 | 106.8 | 85 | 44 | |||
| Company of Heroes 2 | 42.7 | 35.8 | 23.2 | 11 | ||
| GRID 2 | 146.5 | 111.3 | 101.7 | 28.7 | ||
| Metro: Last Light | 71.9 | 57.6 | 34.3 | 18.3 | ||
| BioShock Infinite | 158.1 | 91.8 | 78.3 | 27.9 | ||
| StarCraft II: Heart of the Swarm | 238.2 | 102.1 | 84.6 | 34.5 | ||
| SimCity | 77.6 | 40.9 | 34.5 | 21.7 | ||
| Tomb Raider | 201.1 | 104.9 | 66.5 | 28 | ||
| Crysis 3 | 84.9 | 50.7 | 35 | 13.8 | ||
| Dead Space 3 | 291.4 | 143.9 | 109.7 | 66 | ||
| Far Cry 3 | 110.7 | 82.2 | 44 | 13 | ||
| Assassin´s Creed III | 57.3 | 56 | 21 | |||
| Hitman: Absolution | 69.2 | 59.4 | 31 | 13 | ||
| Call of Duty: Black Ops 2 | 128.4 | 113.1 | 71 | 43 | ||
| Need for Speed: Most Wanted | 60 | 60 | 50 | 29 | ||
| Medal of Honor: Warfighter | 117.1 | 78 | 62.6 | 25 | ||
| Dishonored | 129.3 | 127.2 | 116 | 75 | ||
| World of Tanks v8 | 115.4 | 74.2 | 65.8 | 38.2 | ||
| Fifa 13 | 472.1 | 339.9 | 296.3 | 180.6 | ||
| F1 2012 | 154 | 122 | 111 | 45 | ||
| Borderlands 2 | 109.8 | 96.3 | 70 | 45 | ||
| Guild Wars 2 | 86.1 | 44 | 18 | |||
| Counter-Strike: GO | 244.4 | 222.9 | 164.4 | 95.7 | ||
| Darksiders II | 108.9 | 63.2 | ||||
| Sleeping Dogs | 132.1 | 98.6 | 49 | 13 | ||
| Max Payne 3 | 72.4 | 70 | 33 | 25 | ||
| Dirt Showdown | 93.7 | 73.3 | 76 | 32 | ||
| Diablo III | 236.3 | 165.4 | 144 | 89.5 | ||
| Risen 2: Dark Waters | 88.1 | 61.4 | 48 | 23.4 | ||
| Mass Effect 3 | 59.9 | 59.9 | 57.6 | |||
| Alan Wake | 79.3 | 47.3 | 23 | |||
| Anno 2070 | 228.4 | 102.9 | 63 | 32 | ||
| The Elder Scrolls V: Skyrim | 81.8 | 59 | 33 | |||
| CoD: Modern Warfare 3 | 263.8 | 168.1 | 109.8 | 61 | ||
| Battlefield 3 | 95.6 | 71.9 | 52 | 21 | ||
| < 30 fps < 60 fps < 120 fps ≥ 120 fps | 3 24 18 | 11 25 10 | 2 22 17 4 | 27 12 7 2 | | |
