Rockchip RK3288

 RK3288

Rockchip RK3288是一款为安卓和Chrome OS移动设备设计的中端ARM系统芯片。它集成了四颗Cortex-A12核心,运行于1.8GHz。由于性能水平相似,ARM也将它们分类为Cortex-A17核心。它包括了一颗运行于600MHz的ARM Mali-T760 MP4(或Mali-T764)显卡,以及一个双通道DDR3,DDR3L,LPDDR2,LPDDR3内存控制器。

ARM Cortex-A12是Cortex-A9的后续型号,基于32位ARMv7-A微架构。根据ARM提供的信息,一颗A12核心的性能应该相比A9核心有40%的提升。

它的集成图形引擎支持H.264,VP8和MVC的1080p编码。它支持4K分辨率的H.264和10位H.265解码。

这颗芯片采用28纳米HKMG工艺制造。

Series

Series:

Google Tensor G41.95 GHz8 / 8 cores
HiSilicon Kirin 9000W1.53 - 2.49 GHz12 / 12 cores
Samsung Exynos W10001.5 GHz5 / 5 cores
UNISOC Tiger T3101.8 - 2 GHz4 / 4 cores
Rockchip RK3288 « 1.8 GHz4 / 4 cores
Apple S52 / 2 cores
HiSilicon k3v2 Hi36201.2 GHz4 / 4 cores
Rockchip RK3066 1.5 GHz1.5 GHz2 / 2 cores
Amlogic AML8726-MX1.5 GHz2 / 2 cores
Rockchip RK31681.2 GHz2 / 2 cores
Rockchip RK2918 1.2 GHz1.2 GHz1 / 1 cores
ARM Cortex A8 1.2 GHz1.2 GHz1 / 1 cores
Telechips TCC8803 1GHz1 GHz1 / 1 cores
Loongson 2F 900MHz0.9 GHz1 / 1 cores
CSR86700.08 GHzcores
ARM Cortex-M4 cores
HiSilicon Hi6262 cores
DK3.5+STcores
unknown cores
Clock Rate1800 MHz
Number of Cores / Threads4 / 4
Manufacturing Technology28 nm
FeaturesARM MAli-T624 at 600 MHz, dedicated 2D processor, 1080P H.264, VP8, MVC encoding, 4K H.264 and 10 Bits H.265 decoding, 1080p multi video decode, Dual-channel DDR3(L) memory controller, HDMI 2.0
GPUARM Mali-T760 MP4 (600 MHz)
ArchitectureARM
Announcement Date08/01/2014
Product Link (external)www.rk3288.com

Benchmarks

3DMark - 3DMark Ice Storm Unlimited Physics
15496 Points (13%)
Geekbench 3 - Geekbench 3 32 Bit Multi-Core
min: 1909     avg: 2183     median: 2182.5 (4%)     max: 2456 points
Geekbench 3 - Geekbench 3 32 Bit Single-Core
min: 698     avg: 779     median: 778.5 (15%)     max: 859 points
Mozilla Kraken 1.1 - Kraken 1.1 Total Score *
min: 4753     avg: 5809     median: 5790 (7%)     max: 6884 ms
Sunspider - Sunspider 1.0 Total Score *
min: 745     avg: 746     median: 745.5 (8%)     max: 746 ms
Octane V2 - Octane V2 Total Score
min: 5967     avg: 6798     median: 7107 (6%)     max: 7319 Points
AnTuTu v6 - AnTuTu v6 Total Score
47100 Points (16%)
PCMark for Android - PCM f. Android Work Score
3888 Points (19%)
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance
