Asus Zenbook 14 OLED UM3406HA

Specifications

Asus Zenbook 14 OLED UM3406HA
Asus Zenbook 14 OLED UM3406HA (ZenBook 14 UM3000 Series)
Processor
AMD Ryzen 7 8840HS 8 x 3.3 - 5.1 GHz, 32 W PL2 / Short Burst, 27 W PL1 / Sustained, Hawk Point-HS (Zen 4)
Graphics adapter
AMD Radeon 780M, Core: 2100 MHz, RAM: 1367 MHz, Adrenalin 23.20.42
Memory
16 GB
, LPDDR5x-7467, Dual-Channel, onboard
Display
14.00 inch 16:10, 1920 x 1200 pixel 162 PPI, 3.5mm, ATNA40CT02-0, OLED, glossy: yes, HDR, 60 Hz
Mainboard
AMD Promontory/Bixby FCH
Storage
Micron 2400 MTFDKBA1T0QFM, 1024 GB
, 903 GB free
Soundcard
AMD Zen - Audio Processor - HD Audio Controller
Connections
1 USB 3.0 / 3.1 Gen1, 1 USB 3.1 Gen2, 1 USB 4.0 40 Gbps, USB-C Power Delivery (PD), 1 HDMI, 2 DisplayPort, Audio Connections: 3.5mm, Brightness Sensor
Networking
MediaTek Wi-Fi 6E MT7922 160MHz Wireless LAN Card (a/b/g/n = Wi-Fi 4/ac = Wi-Fi 5/ax = Wi-Fi 6/ Wi-Fi 6E 6 GHz), Bluetooth 5.3
Size
height x width x depth (in mm): 14.9 x 312.4 x 220.1
Battery
75 Wh, 4825 mAh Lithium-Ion, 4-cell
Operating System
Microsoft Windows 11 Home
Camera
Webcam: 1080p + IR
Primary Camera: 2 MPix
Additional features
Speakers: Stereo, Keyboard: Chiclet, Keyboard Light: yes, 65W PSU, 24 Months Warranty
Weight
1.219 kg, Power Supply: 226 g
Price
1199 Euro
Amazon



Price comparison

Average Score: 87.16% - good
Average of 10 scores (from 15 reviews)
price: 80%, performance: 89%, features: 75%, display: 88% mobility: 89%, workmanship: 80%, ergonomy: 86%, emissions: 90%

Reviews for the Asus Zenbook 14 OLED UM3406HA

88.6% 华硕 Zenbook 14 OLED 评测 - AMD 版 Zenbook 配备了较弱的 1080p OLED 屏幕 | Notebookcheck
华硕还推出了搭载 AMD Ryzen 8000 处理器的廉价版 Zenbook 14 OLED,其性能甚至优于流星湖版。不过,它在内存和全高清 OLED 面板(刷新率仅为 60 赫兹)方面受到了限制。
华硕 Zenbook 14 OLED UM3406 评测–性能均衡、电池寿命长
Source: Laptopmedia CN
与英特尔版本相比,Zenbook 14 OLED UM3406 有一个显著优势,那就是更高的 3D 渲染多核性能,而 AMD CPU 在中短期负载下的运行温度较低。说到这一点,Ryzen 7 8840HS 在长时间压力下无法达到官方公布的基本时钟频率,但对于一款轻薄的 14 英寸机器来说,3.00 GHz 的频率看起来并不差。此外,噪音水平似乎也比 Team Blue 版本要低一些。电池续航时间非常出色,一次充电可播放 19 个小时的视频!不过,我们的笔记本电脑配备的是非触摸式 1200p 显示屏。如果你选择配备可选的 2880×1800 120Hz 屏幕的机器,也许自主工作时间会缩短。这提醒我们,默认的 OLED 面板(ATNA40CT02-0 (SDC41A0))非常出色。
Single Review, online available, Very Long, Date: 11/09/2024

Foreign Reviews

ASUS Zenbook 14 OLED UM3406 review – Balanced Performer with Long Battery Life
Source: Laptop Media English EN→zh-CN
The Zenbook 14 OLED UM3406 has one significant advantage over the Intel version and that’s the higher 3D rendering multi-core performance while the AMD CPU runs cooler in in short and medium loads. Speaking of which, the Ryzen 7 8840HS can’t reach its official base clock in long stress but a frequency of ~ 3.00 GHz doesn’t look half bad for a thin and light 14″ machine. Also, the noise levels seem a bit lower than the Team Blue version. The battery life is outstanding – 19 hours of videos on a single charge! Still, this applies to our laptop with a non-touch 1200p display. Perhaps the autonomous work will be tanked if you pick a machine with the optional 2880×1800 120Hz screen.
Single Review, online available, Very Long, Date: 11/09/2024
90% ASUS Zenbook 14 OLED UM3406HA Review – Affordable AMD-powered productivity workhorse laptop
Source: Hitech Century English EN→zh-CN
The ASUS Zenbook 14 UM3406HA with its AMD Ryzen 7 8840HS processor is an excellent general purpose platform for daily computing, moderate content creation and light gaming. Offering a performance envelope capable of giving the Intel Core Ultra 7 equipped version of its sibling a run for its money while running cheaper than the Core Ultra 5 version at RM4,299, it proves to be a well-priced all rounder with superb value.
Single Review, online available, Medium, Date: 07/03/2024
Rating: Total score: 90% price: 80% performance: 100% display: 100% mobility: 90% workmanship: 80%
90% Asus Zenbook 14 OLED UM3406HA review (2024, AMD Ryzen 7 8840HS)
Source: Ultrabook Review English EN→zh-CN
This 2024 Zenbook 14 OLED UM3406HA series built on AMD Hawk Point hardware is one of the best portable daily-driver laptops available today. It's the same chassis as the already versatile Zenbook 14 UX3405 model, but includes somewhat faster hardware for multitasking and sustained loads, comes in an exquisite Jade Black colors, and is generally more affordable than the Intel version, due to the offered configurations and specs.
Single Review, online available, Very Long, Date: 05/27/2024
Rating: Total score: 90%
The $799 Asus Zenbook 14 OLED with Ryzen is a Good Value - UM3406 / UM3406HA
Source: Lon.TV English
Single Review, online available, Very Long, Date: 05/02/2024
80% Asus Zenbook 14 OLED Touch (UM3406) Review
Source: PC Mag English EN→zh-CN
One of Asus' countless other Zenbook 14 OLED models, the AMD Ryzen 7 7730U-based Asus Zenbook 14 OLED UM3402, earned a four-star recommendation in August 2023 and was recently ousted from our ultraportable roundup by none other than the Asus Zenbook 14X OLED (Q420). Joined by today's UM3406 in the under-$900 club, the UM3402 has a sharper screen but we griped that its performance trailed that of Intel systems. (Hence the Q420's recent position.) By contrast, the Ryzen 7 8840HS-packing Asus Zenbook 14 OLED Touch UM3406 can slug it out with Intel's finest and lasted four hours longer on battery power—reason enough to bestow it with our Editors' Choice award for frequent flyers in economy class.
Single Review, online available, Long, Date: 04/09/2024
Rating: Total score: 80%
91% Asus Zenbook 14 OLED review: A budget laptop star
Source: PC World English EN→zh-CN
The Asus Zenbook 14 OLED UM3406 is an exceptional budget laptop. Though it’s not much to look at, it provides great performance across a wide variety of benchmarks, long battery life, solid build quality, an excellent OLED screen, strong speakers, and a quality webcam. Even the laptop’s weaknesses, such as its keyboard and connectivity, are average for the price and competitive with alternatives. This is not a performance or gaming laptop, so it has its limits—but if you’re looking for an excellent all-around Windows laptop at a respectable price, it’s hard to beat.
Single Review, online available, Long, Date: 04/09/2024
Rating: Total score: 91%
90% Asus Zenbook 14 OLED Review (2024): Unassumingly Aiming For Best In Class
Source: Slashgear English EN→zh-CN
The Asus Zenbook was an absolute pleasure to put through its paces. Last year's Zenbook was already a great device, but this year's version improved on its predecessor's shortcomings, namely its processing speed and slower memory. Asus created one of the best sub-$1000 laptops you can buy. Starting at $799, there isn't much to dislike about the Zenbook 14 OLED. The display is beautiful, the laptop is powerful, and it has top-notch performance and surprisingly great battery life. It can even play many of the latest games at satisfying graphical fidelity, making it a well-rounded laptop. The design might be a bit bland for some, but I find it elegant. It's part of the charm of the Zenbook 14 OLED. Asus has a real winner on its hands with this 14-inch laptop. If you are looking for a premium laptop and aren't looking for an Apple device, or a gaming laptop, then the Asus Zenbook 14 OLED (2024) should be your go-to option.
Single Review, online available, Medium, Date: 04/09/2024
Rating: Total score: 90%
Der perfekte Laptop für unterwegs?
Source: Inside Handy German DE→zh-CN
Single Review, online available, Medium, Date: 07/01/2024
Asus Zenbook 14 OLED
Source: Allround-PC.com German DE→zh-CN
Single Review, online available, Long, Date: 05/27/2024
90% ASUS Zenbook 14 OLED, la nostra recensione
Source: Tech Different Italian IT→zh-CN
Single Review, online available, Short, Date: 08/27/2024
Rating: Total score: 90% features: 90% display: 90% mobility: 90%
82% Test Asus Zenbook 14 UM3406H : Du milieu de gamme, parfait pour les tâches de productivité
Source: Charles Tech French FR→zh-CN
Single Review, online available, Very Long, Date: 10/17/2024
Rating: Total score: 82% performance: 80% display: 80% mobility: 80% workmanship: 70%
90% Test du Asus Zenbook 14 OLED 2024 (AMD) : le rouge lui va si bien
Source: Frandroid French FR→zh-CN
Single Review, online available, Long, Date: 06/02/2024
Rating: Total score: 90% performance: 100% display: 90% mobility: 90% workmanship: 80%
80% Asus Zenbook 14 OLED (UM3406HA)
Source: Les Numeriques French FR→zh-CN
Single Review, online available, Very Long, Date: 04/15/2024
Rating: Total score: 80% performance: 80% display: 80% mobility: 100% workmanship: 80%
Test ASUS Zenbook 14 z AMD Ryzen 7 8840HS - Niewielki ultrabook o solidnej wydajności, z ekranem OLED i w dobrej cenie
Source: PurePC Turkish PL→zh-CN
Single Review, online available, Very Long, Date: 07/28/2024

Comment

AMD Radeon 780M:

Ryzen 7040 移动系列 APU 中的集成显卡基于 RDNA3 架构,具有 12 个 CU(= 768 个着色器),时钟速度高达 3 GHz。



» Further information can be found in our Comparison of Mobile Graphics Cards and the corresponding Benchmark List.


R7 8840HS: 2023 年第四季度亮相的一款高端鹰点系列处理器。8840HS 实际上并不是一款新芯片;相反,它与 Ryzen 7 7840U 类似,但最低 TDP 增加了 5 瓦,并采用了更高时钟频率的 Ryzen AI 引擎。8840HS 有 8 个支持 SMT 的内核(16 个线程),运行频率为 3.3 GHz 至 5.1 GHz。这些 Zen 4 架构内核与 Radeon 780M 集成图形适配器相匹配。» Further information can be found in our Comparison of Mobile Processsors.


14.00":

大体上,这个屏幕尺寸常见于亚笔记本电脑,超极本和变形本中。对这三类产品来说这个尺寸都较大。亚笔记本中尺寸最大的机型是采用这个屏幕尺寸。

大尺寸可以让屏幕有更高的分辨率。因而例如字体等的细节将会更丰富。不过另一方面,小屏幕的功耗会较低,而设备也会更轻盈小巧,售价更低。

» To find out how fine a display is, see our DPI List.


1.219 kg: 这是10到11寸大尺寸平板电脑,小型亚笔记本,超极本和变形本的常见重量。


» Further information can be found in our Notebook Purchase Guide.
