戴尔 XPS 15 笔记本电脑简短评测

Name: Dell XPS 15 (9530-0538)
Brand: Dell

更多像素！ 作为戴尔的XPS 15 (2013年底)配备QHD+屏幕，这家美国企业现在推出了更新后的XPS 15，搭配了4K UHD屏幕和更加强大的处理器。几乎完美的屏幕效果和优秀的性能都十分吸引人。遗憾的是，前代产品中存在的一些问题仍然没有得到解决。

Nino Ricchizzi, ✓ Tanja Hinum (translated by Yuchen Wang), Published 03/23/2015 🇺🇸 🇩🇪 ...

Haswell Laptop / Notebook Ultrabook Windows

Test device courtesy of Dell

Download your licensed rating image as PNG / SVG

Dell XPS 15 (9530-0538) (XPS 15 Series)

Processor

Intel Core i7-4712HQ 4 x 2.3 - 3.3 GHz, Haswell

Graphics adapter

NVIDIA GeForce GT 750M - 2048 MB VRAM, Core: 941 MHz, RAM: 1250 MHz, GDDR5, nvlddmkm 9.18.13.4752 (ForceWave 347.52) / Win8.1 64, NIVIDA Optimus

Memory

16 GB

, 双通道, DDR3

Display

15.60 inch 16:9, 3840 x 2160 pixel, 电容型，多点触控, Sharp SHP1431 LQ156D1, IPS, glossy: yes

Mainboard

Intel HM87 (Lynx Point)

Storage

Lite-On LMT-512L9M, 512 GB

Soundcard

Intel Lynx Point PCH - High Definition Audio Controller

Connections

1 USB 2.0, 3 USB 3.0 / 3.1 Gen1, 1 DisplayPort, Audio Connections: 整合音频接口, Card Reader: SD, Noble锁

Networking

Broadcom 802.11ac (a/b/g/n = Wi-Fi 4/ac = Wi-Fi 5/), Bluetooth Bluetooth 4.0

Size

height x width x depth (in mm): 18 x 372 x 253

Battery

88 Wh Lithium-Ion, 6 芯

Operating System

Microsoft Windows 8.1 Pro 64 Bit

Camera

Webcam: 720p

Additional features

Speakers: 立体声扬声器, Keyboard: 孤岛式, Keyboard Light: yes, 24 Months Warranty

Weight

2.1 kg

Price

1850 Euro

Links

Dell homepage
Dell notebook section
XPS 15 (Series)

Note: The manufacturer may use components from different suppliers including display panels, drives or memory sticks with similar specifications.

see all specifications


359 cd/m²	360 cd/m²	355 cd/m²
341 cd/m²	349 cd/m²	350 cd/m²
389 cd/m²	390 cd/m²	394 cd/m²

Distribution of brightness

Sharp SHP1431 LQ156D1 tested with X-Rite i1Pro 2

Maximum: 394 cd/m² (Nits) Average: 365.2 cd/m²
Brightness Distribution: 87 %
Center on Battery: 349 cd/m²
Contrast: 1238:1 (Black: 0.282 cd/m²)
ΔE Color 2.65 | 0.5-29.43 Ø4.92
ΔE Greyscale 3.77 | 0.5-98 Ø5.2
96.1% sRGB (Argyll 1.6.3 3D)
61.02% AdobeRGB 1998 (Argyll 1.6.3 3D)
66.9% AdobeRGB 1998 (Argyll 2.2.0 3D)
96.1% sRGB (Argyll 2.2.0 3D)
64.9% Display P3 (Argyll 2.2.0 3D)
Gamma: 2.41

Download ICC File (X-Rite i1Pro 2)

	Dell XPS 15 (9530-0538) GeForce GT 750M, 4712HQ, Lite-On LMT-512L9M	Dell XPS 15 (Late 2013) GeForce GT 750M, 4702HQ, Samsung SSD SM841 512GB	Apple MacBook Pro Retina 15 inch 2013-10 GeForce GT 750M, 4850HQ, Apple SSD SM0512F	Asus NX500JK-DR018H GeForce GTX 850M, 4712HQ, Samsung SSD XP941 MZHPU256HCGL
Display		7%
Display P3 Coverage	64.9	72.6 12%
sRGB Coverage	96.1	96.1 0%
AdobeRGB 1998 Coverage	66.9	72.9 9%
Screen		-34%	1%	-7%
Brightness middle	349	349 0%	332 -5%	309 -11%
Brightness	365	322 -12%	302 -17%	290 -21%
Brightness Distribution	87	83 -5%	83 -5%	86 -1%
Black Level *	0.282	0.21 26%	0.3326 -18%	0.26 8%
Contrast	1238	1662 34%	998 -19%	1188 -4%
Colorchecker dE 2000 *	2.65	8.27 -212%	1.95 26%	4.69 -77%
Greyscale dE 2000 *	3.77	7.99 -112%	2.11 44%	3.35 11%
Gamma	2.41 ^91%	3.42 ^64%	2.34 ^94%	2.33 ^94%
CCT	6786 ^96%	8117 ^80%	6489 ^100%	6400 ^102%
Color Space (Percent of AdobeRGB 1998)	61.02	69.08 13%	60.6 -1%	83 36%
Color Space (Percent of sRGB)	96.1
Total Average (Program / Settings)		-14% / -22%	1% / 1%	-7% / -7%

* ... smaller is better

Cinebench R11.5
CPU Multi 64Bit (sort by value)
Dell XPS 15 (9530-0538) GeForce GT 750M, 4712HQ, Lite-On LMT-512L9M	6.4 Points
Dell XPS 15 (Late 2013) GeForce GT 750M, 4702HQ, Samsung SSD SM841 512GB	6.29 Points
CPU Single 64Bit (sort by value)
Dell XPS 15 (9530-0538) GeForce GT 750M, 4712HQ, Lite-On LMT-512L9M	1.44 Points
Dell XPS 15 (Late 2013) GeForce GT 750M, 4702HQ, Samsung SSD SM841 512GB	1.38 Points

Cinebench R10
Rendering Multiple CPUs 64Bit (sort by value)
Dell XPS 15 (9530-0538) GeForce GT 750M, 4712HQ, Lite-On LMT-512L9M	22609 Points
Dell XPS 15 (Late 2013) GeForce GT 750M, 4702HQ, Samsung SSD SM841 512GB	22243 Points
Rendering Single CPUs 64Bit (sort by value)
Dell XPS 15 (9530-0538) GeForce GT 750M, 4712HQ, Lite-On LMT-512L9M	6205 Points
Dell XPS 15 (Late 2013) GeForce GT 750M, 4702HQ, Samsung SSD SM841 512GB	6021 Points

Cinebench R10 Shading 64Bit

6499 Points

Cinebench R10 Rendering Multiple CPUs 64Bit

22609 Points

Cinebench R10 Rendering Single CPUs 64Bit

6205 Points

Cinebench R11.5 OpenGL 64Bit

57.1 fps

Cinebench R11.5 CPU Multi 64Bit

6.4 Points

Cinebench R11.5 CPU Single 64Bit

1.44 Points

Cinebench R15 Ref. Match 64Bit

99.6 %

Cinebench R15 OpenGL 64Bit

74.5 fps

Cinebench R15 CPU Multi 64Bit

565 Points

Cinebench R15 CPU Single 64Bit

125 Points

Help

... in comparison

	Dell XPS 15 (9530-0538) GeForce GT 750M, 4712HQ, Lite-On LMT-512L9M	Dell XPS 15 (Late 2013) GeForce GT 750M, 4702HQ, Samsung SSD SM841 512GB	Apple MacBook Pro Retina 15 inch 2013-10 GeForce GT 750M, 4850HQ, Apple SSD SM0512F	Asus NX500JK-DR018H GeForce GTX 850M, 4712HQ, Samsung SSD XP941 MZHPU256HCGL
PCMark 7		19%	17%	2%
Score	5549	5937 7%	5842 5%	5565 0%
Lightweight	3555	3678 3%		3748 5%
Productivity	2782	2878 3%	5357 93%	2911 5%
Entertainment	4000	10503 163%	4674 17%	3907 -2%
Creativity	10028	4481 -55%	9329 -7%	10264 2%
Computation	17929	19543 9%	10885 -39%	17559 -2%
System Storage	5392	5562 3%	7136 32%	5608 4%

PCMark 7 Score		5549 points
Help

... in comparison

AS SSD
Seq Read (sort by value)
Dell XPS 15 (9530-0538) GeForce GT 750M, 4712HQ, Lite-On LMT-512L9M	486.2 MB/s
Dell XPS 15 (Late 2013) GeForce GT 750M, 4702HQ, Samsung SSD SM841 512GB	498.5 MB/s +3%
Seq Write (sort by value)
Dell XPS 15 (9530-0538) GeForce GT 750M, 4712HQ, Lite-On LMT-512L9M	373.5 MB/s
Dell XPS 15 (Late 2013) GeForce GT 750M, 4702HQ, Samsung SSD SM841 512GB	404.9 MB/s +8%
4K Read (sort by value)
Dell XPS 15 (9530-0538) GeForce GT 750M, 4712HQ, Lite-On LMT-512L9M	29.65 MB/s
Dell XPS 15 (Late 2013) GeForce GT 750M, 4702HQ, Samsung SSD SM841 512GB	23.83 MB/s -20%
4K Write (sort by value)
Dell XPS 15 (9530-0538) GeForce GT 750M, 4712HQ, Lite-On LMT-512L9M	62 MB/s
Dell XPS 15 (Late 2013) GeForce GT 750M, 4702HQ, Samsung SSD SM841 512GB	59.6 MB/s -4%

CrystalDiskMark 3.0

AS SSD

Lite-On LMT-512L9M

Sequential Read: 485.2 MB/s

Sequential Write: 425.4 MB/s

512K Read: 375.5 MB/s

512K Write: 403 MB/s

4K Read: 32.41 MB/s

4K Write: 70.2 MB/s

4K QD32 Read: 386.3 MB/s

4K QD32 Write: 338.6 MB/s

3DMark
1280x720 Cloud Gate Standard Score (sort by value)
Dell XPS 15 (9530-0538)	10521 Points
Dell XPS 15 (Late 2013)	9739 Points -7%
1920x1080 Fire Strike Score (sort by value)
Dell XPS 15 (9530-0538)	2049 Points
Dell XPS 15 (Late 2013)	1953 Points -5%
1280x720 Ice Storm Standard Score (sort by value)
Dell XPS 15 (9530-0538)	70949 Points
Dell XPS 15 (Late 2013)	55377 Points -22%

3DMark 11 - 1280x720 Performance (sort by value)
Dell XPS 15 (9530-0538)	2971 Points
Dell XPS 15 (Late 2013)	2974 Points 0%

Legend

Dell XPS 15 (9530-0538) Intel Core i7-4712HQ, NVIDIA GeForce GT 750M, Lite-On LMT-512L9M

Dell XPS 15 (Late 2013) Intel Core i7-4702HQ, NVIDIA GeForce GT 750M, Samsung SSD SM841 512GB

3DMark 11 Performance		2971 points
3DMark Ice Storm Standard Score		70949 points
3DMark Cloud Gate Standard Score		10521 points
3DMark Fire Strike Score		2049 points
Help

... in comparison

BioShock Infinite
1920x1080 Ultra Preset, DX11 (DDOF) (sort by value)
Dell XPS 15 (9530-0538)	22.04 fps
Dell XPS 15 (Late 2013)	21.85 fps -1%
1366x768 High Preset (sort by value)
Dell XPS 15 (9530-0538)	60 fps
Dell XPS 15 (Late 2013)	61.1 fps +2%

Legend

Dell XPS 15 (9530-0538) Intel Core i7-4712HQ, NVIDIA GeForce GT 750M, Lite-On LMT-512L9M

Dell XPS 15 (Late 2013) Intel Core i7-4702HQ, NVIDIA GeForce GT 750M, Samsung SSD SM841 512GB

	low	med.	high	ultra
BioShock Infinite (2013)	121.7	77.3	60	22.04

Noise Level

Idle		29.6 / 31.6 / 31.6 dB(A)
Load		45.4 / 45.4 dB(A)

	30 dB silent 40 dB(A) audible 50 dB(A) loud
min: , med: , max: Voltcraft sl-320 (15 cm distance)

Max. Load

Idle


41.3 °C	51.8 °C	44 °C
46.1 °C	48.9 °C	34.5 °C
30.8 °C	29 °C	30.5 °C

Maximum: 51.8 °C
Average: 39.7 °C


48.5 °C	64.6 °C	48.5 °C
31.2 °C	40 °C	37 °C
29.3 °C	29 °C	28.5 °C

Maximum: 64.6 °C
Average: 39.6 °C

Power Supply (max.) 49 °C | Room Temperature 24.3 °C | Voltcraft IR-360

(-) The average temperature for the upper side under maximal load is 39.7 °C / 103 F, compared to the average of 31.3 °C / 88 F for the devices in the class Multimedia.
(-) The maximum temperature on the upper side is 51.8 °C / 125 F, compared to the average of 36.9 °C / 98 F, ranging from 21.1 to 71 °C for the class Multimedia.
(-) The bottom heats up to a maximum of 64.6 °C / 148 F, compared to the average of 39.2 °C / 103 F
(±) In idle usage, the average temperature for the upper side is 33.1 °C / 92 F, compared to the device average of 31.3 °C / 88 F.
(+) The palmrests and touchpad are cooler than skin temperature with a maximum of 30.8 °C / 87.4 F and are therefore cool to the touch.
(±) The average temperature of the palmrest area of similar devices was 28.8 °C / 83.8 F (-2 °C / -3.6 F).

Power Consumption

Off / Standby	0.2 / 0.9 Watt
Idle	14.6 / 19.6 / 19.8 Watt
Load	92 / 85.8 Watt


Key: min: , med: , max: Voltcraft VC 940

Battery Runtime - WiFi Websurfing (sort by value)
Dell XPS 15 (9530-0538)	314 min

Legend

Dell XPS 15 (9530-0538) Intel Core i7-4712HQ, NVIDIA GeForce GT 750M, Lite-On LMT-512L9M

Pros

+ 高亮度

+ 优秀的出厂色彩还原

+ 屏幕可通过校色优化

+ 高分辨率

+ 高质量机身

Cons

- 可能会有屏幕显示缩放比例问题

- 负载下温度较高

- 镜面屏幕

- 相比前代产品能耗较高

戴尔XPS 15仍然是一款抢眼的产品。在笔记本的机身和输入设备方面，戴尔做得十分出色，不过它最大亮点是全新的4K屏幕。它的优势不仅在于分辨率——它较高的平均亮度和准确的色彩与灰阶都堪称典范。尽管它的对比度相比前代产品较低，但由于快速的硬件配置，戴尔XPS 15仍然会给用户带来很多的享受。戴尔再次创造了一款全功能的多媒体产品——尽管售价达1850欧元（约12511人民币），它物有所值。如果戴尔能够为它配备更加强大的显卡的话游戏玩家可能会更高兴，不过目前还没有这样的升级选项。

注：本文是基于完整评测的缩减版本，阅读完整的英文评测，请点击这里。

Dell XPS 15 (9530-0538) - 2015-03-06 03/06/2015 v4 ^(old)
Nino Ricchizzi

Chassis

95 / 98 → 97%

Keyboard

88%

Pointing Device

81%

Connectivity

67 / 81 → 83%

Weight

90 / 20-67 → 100%

Battery

89%

Display

88%

Games Performance

84 / 85 → 99%

Application Performance

94 / 92 → 100%

Temperature

80%

Noise

80 / 95 → 84%

Audio

70%

Camera

68 / 85 → 80%

Average

83%

87%

Multimedia - Weighted Average
